APA 16547NV 5-in-1 Power Pack Jump Starter and Voltage Converter

Name: APA 16547NV 5-in-1 Power Pack Jump Starter and Voltage Converter
Brand: APA

The APA 16547NV 5-in-1 Power Pack is a versatile portable power solution featuring a 12V jump starter, integrated air compressor, 230V voltage converter, dual USB charging ports, and 12V power outlets.

Table of contents

Product Overview

The APA 16547NV 5-in-1 Power Pack is a multi-functional device designed for automotive and leisure use. It serves as a 12V jump starter, an air compressor for tires and sports equipment, a 230V voltage converter (up to 150W), a dual USB charger, and a 12V power supply.

Safety Precautions

Always wear protective goggles and clothing when handling lead-acid batteries.
Do not attempt to jump start a vehicle with a frozen battery.
Ensure the voltage converter air vent on the back is never obstructed to prevent overheating.
Keep the device away from children.
Never operate the voltage converter while the Power Pack is being charged.

Operation

Charging

Charge the unit fully before first use. It can be charged via the included plug charger (approx. 34 hours) or a 12V vehicle charging cable (approx. 12 hours). Do not leave the charger connected for more than 48 hours.

Jump Starting

Ensure the unit is fully charged. Connect the red (+) clamp to the vehicle's positive terminal and the black (-) clamp to the engine block or chassis, away from the battery. Turn the starting aid switch to ON and attempt to start the engine for no more than 6 seconds. Wait at least 5 minutes between attempts.

Compressor

Remove the air hose from the storage compartment. Attach the appropriate valve adapter if necessary. Monitor the pressure using the built-in manometer. Do not run the compressor for more than 10 minutes continuously to avoid overheating.

Voltage Converter & USB

The 230V socket provides up to 150W of continuous power. Ensure the connected device does not exceed this limit. The USB ports are suitable for charging mobile devices.

Maintenance and Troubleshooting

Store in a dry, frost-free location. If not used for long periods, recharge every two months in winter and every month in summer. If the unit fails to operate, check the 15A fuses located on the front and rear panels. Replace only with equivalent flat fuses.

Environmental Protection

Do not dispose of this device in household waste. It contains a lead-acid battery and electronic components that must be recycled at designated collection points.
