Clarke CON1500DD 1500W SDS Demolition Hammer

Product Overview

The Clarke CON1500DD is a high-performance 1500W demolition hammer engineered for heavy-duty tasks such as breaking breeze blocks, brick, hard earth, and concrete. It is designed for durability and efficiency in demanding work environments.

Technical Specifications

• Rated Input Power: 1500W
• Chuck Type: SDS HEX 30mm
• Impact Energy: 45 Joules
• Impact Rating: 1900 blows/min
• Weight: 17.35 kg
• Insulation Class: II
• Sound Pressure Level: 91.8 dB LpA

Safety Precautions

Always read all instructions before use. Failure to follow safety guidelines may result in electric shock, fire, or serious injury. Ensure the work area is clean, well-lit, and free of bystanders. Always wear appropriate personal protective equipment, including a dust mask, non-skid safety shoes, and hearing protection. Be aware of Hand Arm Vibration Syndrome (HAVS) and take regular breaks if you experience numbness or pain.

Setup and Operation

Before starting, check the oil level in the chamber; it should be approximately 3mm above the oil gauge window. The auxiliary handle can be adjusted to the left, right, or center for optimal control. To insert a chisel, clean and grease the shank, rotate the stop lever 180 degrees, insert the bit, and lock it by rotating the lever back. Always ensure the tool is disconnected from the power supply before making adjustments or changing accessories.

Maintenance and Servicing

Regular maintenance is essential for tool longevity. After each use, remove the chisel and clean the chuck area. Keep the handle free from oil and grease. Use a soft brush or cloth for cleaning; do not use harsh chemicals. Periodically clear ventilation holes using compressed air (max 3 bar) while wearing eye protection. Worn or damaged parts must be replaced by qualified personnel using identical spare parts.

Disposal

This product must not be disposed of with general household waste. It must be treated in accordance with WEEE regulations at a recognized disposal facility.
