Installation Guide for Danfoss EVRA Size 15 Overhaul Kit 032F2209
Quick installation guide and parts breakdown for the Danfoss EVRA size 15 valve overhaul kit (032F2209). Includes an exploded view diagram and component list for maintenance.
Table of contents
Quick Guide from the Manual
This document provides the installation and parts breakdown for the Danfoss 032F2209 overhaul kit, designed specifically for the EVRA size 15 valve (previous design). Use this guide to identify components and their correct assembly order during valve maintenance.
Exploded View and Parts Identification
The provided diagram illustrates the assembly sequence of the EVRA valve. Use the numbered reference points (1-12) to identify the correct placement of components during the overhaul process. Ensure the valve is properly depressurized and isolated from the system before beginning any maintenance work.
Component List
The kit contains the following components. Verify all parts are accounted for before beginning the installation:
- 1: Valve stem/spindle assembly (Total: 1)
- 2: Spring/Internal component (Total: 1)
- 3: Washer/Seal (Total: 1)
- 4: Fasteners/Bolts (Total: 4)
- 5: Rubber seal/O-ring (Total: 1)
- 6: Fasteners/Bolts (Total: 4)
- 7: Valve plate/disc (Total: 1)
- 8: Rubber seal/O-ring (Total: 1)
- 9: Fibre gasket/seal (Total: 2)
- 10: Internal pin/rod (Total: 1)
- 11: Nut/Fitting (Total: 1)
- 12: Small washer/seal (Total: 1)
Manufacturer information
Danfoss A/S
Practical help
Before use
- Verify the valve is an EVRA size 15 (previous design) model.
- Ensure all 12 components listed in the kit are present.
- Depressurize the system completely before attempting any valve maintenance.
- Clean all mating surfaces thoroughly before installing new seals.
Specs in practice
- EVRA size 15
- Compatible valve model series (previous design).
