This document provides the assembly diagram and parts list for the Danfoss 032F2341 Overhaul Kit, designed for EVRA size 32 valves. Use this guide to identify the correct placement of spare parts during maintenance or repair. Ensure the system is depressurized before attempting any service.

Exploded view and component identification

The provided diagram illustrates the internal structure of the EVRA valve. Each component is numbered from 1 to 15, corresponding to the parts included in the overhaul kit. Ensure all parts are correctly oriented and seated according to the diagram before reassembling the valve.

Exploded view of the EVRA size 32 valve assembly

Included components

The kit contains the following specific spare parts:

1: Ø14 mm (Qty: 1)
2: Ø27 mm, Alu. (Qty: 2)
3: Ø10 mm, Alu. (Qty: 1)
4: Ø66 mm (Qty: 2)
5: Ø42 mm (Qty: 1)
7: 42.5 mm (Qty: 1)
8: Ø3.3 mm (Qty: 1)
9: Ø44 mm, Steel (Qty: 1)
10: (Qty: 1)
11: Ø38 mm (Qty: 1)
12: Ø17 mm (Qty: 1)
13: 51 mm (Qty: 1)
14: Ø4 mm (Qty: 1)
15: (Qty: 1)

Manufacturer information

Danfoss A/S

Brand profile

Manufacturer website https://www.danfoss.com Support https://www.danfoss.com/en/service-and-support/ Manufacturer manuals https://www.danfoss.com/en/service-and-support/downloads/

Practical help

Common problems

Difficulty identifying part placement

Refer to the exploded view diagram where each part is numbered 1-15, showing its specific location within the valve assembly.

Missing parts during assembly

Verify the quantity of each part against the 'Total no.' listed in the guide (e.g., Part 2 requires 2 units, Part 3 requires 1 unit).

Before use

Ensure the system is fully depressurized before starting maintenance.
Verify that the valve is an EVRA size 32 model.
Compare the contents of the kit against the provided parts list to ensure all items are present.
Clean all mating surfaces before installing new parts.
