Hama Safety 150W Car Power Inverter
Reliable 150W car power inverter for converting 12V DC vehicle power to standard AC output, featuring comprehensive safety protections and compact design.
Table of contents
Product Overview
The Hama Safety 150W Car Power Inverter is designed to provide a reliable source of AC power within your vehicle. It converts 12V DC power from your car's cigarette lighter socket into standard AC power, allowing you to operate small electronic devices on the go. The unit is built with multiple safety features to protect both the connected equipment and your vehicle's electrical system.
Getting Started
Before connecting any device, verify its power consumption in watts or VA. Ensure that the total power requirement does not exceed the inverter's continuous output capacity of 150W. To operate the device:
- Ensure the inverter's power switch is in the 0 (off) position.
- Insert the cigarette lighter plug firmly into the vehicle's socket, ensuring a secure connection without strain on the cable.
- Switch the inverter on by moving the power switch to the I position.
Caution: Always ensure that the plug and socket contacts are clean and free of debris to prevent voltage drops, sparking, or overheating.
Safety and Protection Features
The inverter includes several built-in protection mechanisms to ensure safe operation:
- Residual current protection: Deactivates if a residual current of at least 30 mA is detected.
- Short circuit protection: Automatically shuts down in the event of a short circuit.
- Low voltage protection: Triggers an alarm if battery voltage drops to 10.5V and shuts down at 10.0V.
- Overvoltage protection: Shuts down if input voltage reaches 15.0V or higher.
- Overload protection: Deactivates if the 150W continuous output is exceeded for extended periods or if a pulse load exceeds 375W.
- Heat protection: Automatically shuts down if the internal temperature reaches 60°C.
Troubleshooting and Maintenance
If the inverter stops working, check the plug-in fuse located on the rear of the unit. Only replace it with a 20A automotive fuse. If the fuse blows repeatedly, check the input polarity and ensure the vehicle's cigarette lighter circuit is not overloaded. Do not attempt to open the device. If you notice smoke, unusual odors, or physical damage to the housing or cables, discontinue use immediately and contact support.
Technical Specifications
- Input Voltage: 12V DC (10V-15V range)
- Continuous Output: 150W
- Peak Output: 375W
- Output Waveform: Modified sine wave
- Efficiency: > 85%
- Operating Temperature: -15°C to +50°C
- Dimensions: 192 x 95.6 x 64.5 mm
- Weight: 834 g
