HOFTRONIC T8 LED Tube Eco Nano 160lm/W

Product Overview

The HOFTRONIC T8 LED Tube Eco Nano 160lm/W is a high-efficiency LED lamp designed to replace traditional linear fluorescent tubes. It features a double-capped (T8 G13) design and is intended for single-ended power supply configurations.

Technical Specifications

• Voltage: 220-240V AC, 50/60Hz
• Power: 12.5W (120cm) or 15.5W (150cm)
• Luminous Flux: 2000lm or 2480lm
• Beam Angle: 320 degrees
• Lifespan: 20,000 hours
• Protection: IP20, Class II

Safety Instructions

Installation must be performed by a qualified electrician in compliance with local electrical regulations. Ensure the power supply is completely disconnected before starting. This product is for indoor use only and must not be used with dimmers or in emergency luminaires unless explicitly approved.

Installation

The LED tube supports three main installation methods:

• Standard: Direct connection to 230V mains.
• Magnetic Ballast Retrofit: Remove the existing starter and replace it with the supplied LED starter.
• Electronic Ballast Retrofit: Remove the ballast from the circuit entirely. This modification must be performed by a certified professional.

Warning: If the ballast is removed or bypassed, the luminaire must be permanently marked with a label stating it has been modified for LED tube use only and that fluorescent lamps should not be installed.

Maintenance and Disposal

Maintenance should only be performed when the power is off and the lamp has cooled. Clean with a soft, dry cloth; do not use chemical detergents. The product is non-demountable and not suitable for independent repairs. At the end of its life, the product must be disposed of via selective collection for electronic waste, as indicated by the crossed-out wheelie bin symbol.
