Ideal Evojet 150kW Condensing Pressure Jet Boiler

Product Overview

The Ideal Evojet 150kW is a high-efficiency, floor-standing condensing boiler designed for commercial applications. It features a titanium-stabilized stainless steel heat exchanger, ensuring maximum resistance to acid condensation. The unit is engineered for versatility, supporting single or multiple configurations and offering compatibility with Natural Gas, LPG, or Oil through various burner options.

Key Features

• High Efficiency: Achieves up to 109.3% part-load efficiency with a triple flue pass design.
• Advanced Controls: Supports modulation via 0-10V BMS or RWF controllers, with options for two-stage or modulating burners.
• Flexible Operation: Designed for central heating and indirect domestic hot water production in fully pumped sealed systems.
• Low Emissions: Engineered for low NOx performance, meeting modern environmental standards.

Technical Specifications

The 150kW model has a dry weight of 510kg and dimensions of 1315mm (H) x 760mm (W) x 1455mm (D). It operates with a maximum working pressure of 6 bar and requires a 230V 50Hz electrical supply. The boiler includes standard high-limit protection, temperature gauges, and safety thermostats.

Installation and Clearances

Proper positioning is critical for maintenance and safety. The following minimum clearances must be maintained:

• Front: Burner length + 600mm for access and maintenance; boiler length for cleaning.
• Sides, Rear, and Top: 1000mm minimum.

Maintenance and Safety

The boiler includes built-in fault diagnosis for both the unit and external components like sensors or pumps. Regular maintenance should be performed by qualified professionals to ensure the integrity of the stainless steel heat exchanger and the efficiency of the burner system. The unit is designed for long-term reliability with a 2-year warranty.
