IZZY 14.8V G7 Handheld Stick Vacuum Cleaner User Guide
Quick guide for the IZZY 14.8V G7 handheld stick vacuum cleaner. Includes charging instructions, operation modes, accessory usage, and maintenance steps for filters and the dust container.
Table of contents
Manual images
Jump to the sectionQuick guide from the manual
This document provides essential instructions for operating and maintaining the IZZY 14.8V G7 handheld stick vacuum cleaner. Key procedures include proper charging, filter maintenance, and safe usage conditions. Always ensure the device is switched off before performing any maintenance or changing accessories.
Charging the appliance
The device can be charged directly via the battery or by placing the vacuum on the charging base. A full charge takes approximately 5 hours. The device will not operate while charging. Ensure the charging base is on a flat, stable surface and avoid charging at temperatures below 0°C or above 37°C.
Using the appliance
To start, remove the vacuum from the base and press the power button. The device defaults to ECO mode. Use the speed adjustment button to toggle between ECO and MAX modes. After use, empty the dust container by pressing the release button.
Using the accessories
The vacuum includes a 2-in-1 nozzle for corners and crevices, a sofa brush for upholstery, and a tube extension. Ensure the device is off before attaching or removing any accessories.
Maintenance and cleaning
Empty and clean the dust container and filters after every use. Remove the container by pressing the release button, then remove the metal and HEPA filters by turning them counterclockwise. Wash these parts with lukewarm water (no detergent) and ensure they are completely dry before reassembly.
Safety and warnings
Do not use the vacuum to pick up liquids, sharp objects, hot materials, or flammable substances. Keep the device away from heat sources and do not use it outdoors or on wet surfaces. Any unauthorized repairs will void the warranty.
Manufacturer information
IZZY
Practical help
Common problems
Device does not work during charging
This is normal; the appliance is designed not to operate while connected to the charger.
Indicator light flashes
This indicates the battery is weak and needs to be recharged.
Reduced airflow or suction
Check if the container or filters are clogged. Empty the container and clean the filters thoroughly.
Before use
- Ensure the dust container and filters are correctly installed.
- Verify the device is switched off before attaching accessories.
- Check that the suction port and air vents are free of obstructions.
- Ensure the battery is charged (approx. 5 hours for full charge).
Specs in practice
- Autonomy (ECO mode)
- Approximately 45±5 minutes depending on debris amount.
- Autonomy (MAX mode)
- Approximately 20±5 minutes depending on debris amount.
Images and diagrams
- The control panel (4) features buttons for power (24) and speed adjustment (23), with indicators for battery level (20), filter blockage (21), and mode status (22, 25).
- The dust container (5) is removed by pressing the release button (8) and emptied via button (9).
Model compatibility
- Use only original spare parts.
- The device is intended for indoor domestic use only.
