Philips Projectline Batten Installation and Usage Guide

Product Overview

The Philips Projectline Batten is a high-quality, energy-efficient LED lighting solution designed for versatile indoor applications. These luminaires provide reliable illumination and are built to meet modern electrical standards. The series includes various models with different lumen outputs and color temperatures to suit diverse lighting requirements.

Technical Specifications

The Projectline Batten series operates on a standard 220V-240V 50/60Hz power supply. Key technical details for the models include:

• Power Consumption: 16W for 60cm models and 30W for 120cm models.
• Color Temperature: Available in 3000K (warm white) and 4000K (cool white) options.
• Lumen Output: Ranges from 1440lm to 3000lm depending on the specific model.
• Energy Efficiency: Classified as energy efficiency class F.
• Lifespan: Designed for long-term operation with a rated LED life of 30,000 hours.

Safety and Installation

Safety is paramount when installing lighting equipment. Please adhere to the following guidelines:

• Qualified Personnel: The luminaire must be installed by a qualified electrician in accordance with the latest IEE electrical regulations or national requirements.
• Environment: Do not install the luminaire in corrosive environments where hazardous materials such as sulphur, chlorine, or phthalates are present.
• Maintenance: The LED driver is not serviceable and not replaceable. The light source contained in this luminaire shall only be replaced by the manufacturer or their service agent or a similar qualified person.
• Electrostatic Sensitivity: Handle the device with care as it contains electrostatic-sensitive components.

Mounting Instructions

The installation process involves securing the mounting brackets to the ceiling or wall surface. Ensure the surface is stable and capable of supporting the weight of the fixture. Use the provided mounting points to click the batten securely into place. Ensure all electrical connections are made within a suitable terminal box that meets local safety standards. Always verify that the power is disconnected before beginning any installation or maintenance work.
