Sigma 14249BR Outlet Box Cover Installation Guide
Quick installation guide for the Sigma 14249BR all-weather horizontal GFCI outlet box cover. Includes safety warnings, mounting steps, and component identification.
Table of contents
Quick guide from the manual
The Sigma 14249BR is an all-weather, horizontal-mount outlet box cover designed for GFCI receptacles. This guide provides the necessary steps for safe installation. Always ensure power is turned off before beginning any electrical work.
Safety and installation requirements
- Installation must be performed by a certified electrician or qualified person.
- All work must comply with the National Electrical Code and applicable local codes.
- Ensure power is completely turned off at the source before starting.
- The package includes the cover, gasket, and mounting screws.
Installation procedure
- Wire the electrical device according to the manufacturer's specific instructions.
- Mount the device securely to the outlet box following the manufacturer's guidelines.
- Ensure all unused holes in the outlet box are properly closed.
- Prepare the gasket by removing tear-outs as required to fit your specific device.
- Attach the gasket and cover to the outlet box using the provided screws, ensuring the hinges are positioned at the top.
Practical help
Common problems
Remove the tear-outs from the gasket as required to accommodate your specific receptacle device.
Installation must be performed by a certified electrician to prevent serious injury or death.
Before use
- Verify power is turned off at the circuit breaker.
- Ensure the outlet box is compatible with horizontal mounting.
- Check that all necessary components (gasket, screws, cover) are present.
- Confirm the device is a GFCI receptacle suitable for this cover type.
