Quick guide from the manual
This document provides technical specifications and performance data for the Sunco UFO High Bay LED Fixture. This fixture is designed for indoor use and features a 90-degree beam spread with multiple mounting options.
Product Overview
The Sunco UFO High Bay LED Fixture is a dimmable lighting solution suitable for warehouses, gymnasiums, retail spaces, gas stations, and highway toll stations. It supports multiple mounting options, including hooks, ceiling mounts, and 1/2 inch NPT pole mounts.
Specifications
- Voltage: 100VAC-277VAC
- Wattage: 150W
- Lumens: 21000lm
- Equivalency: 600W
- Frequency: 50/60Hz
- Power Factor: >90
- Efficacy: 145
- Dimmable: 0-10V
- Beam Angle: 90 degrees
- Color Rendering Index (CRI): 80+
- Color Temperature: Available in 3500K, 4000K, 4500K, 5000K, 6000K, 6500K, 7000K
Operating Environment
The fixture is rated for indoor use only. The operating temperature range is -13°F to 122°F.
Construction and Lifetime
- Housing Material: Aluminum Alloy
- Weight: 3.7 lbs
- Average Lifetime: 50,000 hours
- Warranty: 7 years
Practical help
Before use
- Verify the supply voltage is between 100VAC and 277VAC.
- Ensure the installation location is indoors.
- Confirm the mounting surface can support the 3.7 lbs weight of the fixture.
- Check that the desired color temperature matches the specific model purchased.
Specs in practice
- Voltage: 100-277VAC
- Ensure your power supply matches this range.
- Dimmable: 0-10V
- Requires a compatible 0-10V dimmer switch for dimming functionality.
- Operating Temp: -13°F to 122°F
- Do not install in environments exceeding these temperature limits.
