The Home Depot 130-CPC1 Plastic Accent Side Chair Assembly Instructions

Quick assembly guide for the 130-CPC1 Plastic Accent Side Chair. Includes a complete component list and step-by-step visual instructions for attaching the seat to the base.

Table of contents

Manual images

Jump to the section
Exploded view of the chair assembly showing the seat, base, and hardware alignment. Page 1 Detailed view of the bolt, washers, and Allen key usage. Page 1

Quick guide from the manual

This document provides the necessary steps to assemble the 130-CPC1 Plastic Accent Side Chair. Ensure all components are present before beginning the assembly process.

Component list

  • A: Seat (1 pc)
  • B: Base (1 pc)
  • C: Washer (4 pcs)
  • D: Spring washer (4 pcs)
  • E: Bolt (4 pcs)
  • F: Foot pad (4 pcs)
  • G: Allen key (1 pc)

Assembly instructions

Exploded view of the chair assembly showing the seat, base, and hardware alignment.
Exploded view of the chair assembly showing the seat, base, and hardware alignment.
Detailed view of the bolt, washers, and Allen key usage.
Detailed view of the bolt, washers, and Allen key usage.
  1. Attach the foot pads (F) to the bottom of the base (B).
  2. Place the seat (A) over the base (B), aligning the holes on the seat with the mounting points on the base.
  3. Insert the bolt (E) through the spring washer (D) and then the washer (C).
  4. Secure the seat to the base using the prepared bolt assembly and the provided Allen key (G). Repeat for all four mounting points.
