This document provides essential technical specifications and physical dimensions for the Verbatim 12W LED Integrated Recessed Downlight. This unit is a non-dimmable, maintenance-free lighting solution intended to replace traditional CFL downlights.
Product Overview
The Verbatim LED Integrated Recessed Downlight is a compact lighting fixture. Key features include:
- Easy installation process.
- Non-dimmable operation.
- No maintenance required.
- Designed for a 125mm ceiling cutout.
Technical Specifications
The following specifications apply to the 12W model (Order Code: 66358):
- Wattage: 12W
- Voltage: 220-240V
- Luminous Flux: 900 lm
- Color Temperature (CCT): 6500K (Daylight)
- Beam Angle: 110°
- Lifetime (L70): 15,000 hours
- Operating Temperature: -20°C to 40°C
- CRI: >80
Installation Dimensions
Ensure the installation area meets the following physical requirements:
- Cutout Diameter: 125mm
- Outer Diameter: 140mm
- Height (including driver): 38mm
- Weight: 105g
Practical help
Common problems
This model is non-dimmable; do not use with dimmer switches.
Before use
- Ensure the ceiling cutout is exactly 125mm.
- Verify the power supply is 220-240V.
- Check that the installation space allows for 38mm height clearance.
- Confirm the environment temperature is between -20°C and 40°C.
