This document serves as a technical specification sheet for the Verbatim 16W LED Integrated Recessed Downlight (Order Code 66360). It provides essential data for installation and compatibility verification. This unit is designed for indoor use and is non-dimmable.
Technical Specifications
- Wattage: 16W
- Voltage: 220-240V
- Luminous Flux: 1200 lm
- Color Temperature (CCT): 4000K (Cool-white)
- Beam Angle: 110°
- CRI: >80
- Lifetime: 15000 hrs
- Power Factor: >0.5
Installation and Dimensions
Proper installation requires specific ceiling preparation to ensure a secure fit:
- Cut-Hole Size: 150mm
- Outer Diameter: 165mm
- Height: 38mm (including driver)
- Weight: 142g
Operating Conditions
- Operating Temperature: -20°C to 40°C
- Dimmability: Non-dimmable
- Maintenance: No maintenance required
Practical help
Common problems
This model is non-dimmable; do not connect to a dimmer switch.
Ensure the ceiling cutout is exactly 150mm in diameter.
Before use
- Verify voltage is 220-240V
- Ensure ceiling cutout is 150mm
- Confirm non-dimmable requirement
- Check operating temperature range (-20 to 40°C)
