Hitachi CC 14SE High Speed Cut-Off Saw

Product Overview

The Hitachi CC 14SE is a high-performance cut-off machine engineered for cutting various metallic materials, including pipes, round bars, shaped steel, and siding boards. It features a powerful motor and a 355mm reinforced resinoid cut-off wheel for efficient and precise cutting.

Technical Specifications

• Input Power: 1640W (110V-127V) / 2000W (230V-240V)
• No-Load Speed: 3700 min-1
• Max. Cutting Dimensions (90°): 115mm x 130mm (110V-127V) / 70mm x 235mm (230V-240V)
• Weight: 17 kg

Safety Precautions

Always follow basic safety precautions to reduce the risk of fire, electric shock, and personal injury. Ensure the work area is clean, well-lit, and free of flammable materials. Always wear safety glasses and ear protection. Never operate the machine without the protective guard in place. Ensure the workpiece is securely fastened in the vise before starting the cut.

Operation

To operate, ensure the power switch is in the OFF position before plugging in. Secure the workpiece between the vises (A) and (B) using the clutch and screw handle. The machine allows for angled cuts at 0°, 30°, and 45°. To cut, pull the trigger, rotate the wheel, and gently press down the handle. Do not force the tool; excessive pressure can overload the motor.

Maintenance and Inspection

Regular maintenance is essential for longevity and safety. Always disconnect the power plug before inspection. Regularly inspect the carbon brushes and replace them when they reach the wear limit. Keep the machine clean, wipe off chips and waste, and ensure ventilation openings are clear. Lubricate the rotary parts of the shaft and vise, and the slide way of the vise (A) once a month. Report any faults in the machine, guards, or blades immediately.

Troubleshooting and Disposal

If the machine exhibits excessive vibration or other defects, stop immediately and investigate the cause. For repairs, modifications, or inspections, contact an authorized Hitachi Service Center. Follow local regulations for the disposal of the tool and its components.
