HYUNDAI 57707 14000W Wet/Dry Vacuum Cleaner

Powerful 1400W wet and dry vacuum cleaner designed for versatile cleaning tasks, featuring an integrated power tool socket for automatic operation and a 30L tank capacity.

Table of contents

Product Overview

The Hyundai 57707 is a high-performance wet/dry vacuum cleaner designed to handle both dry dust and debris as well as liquid spills. It features a robust 1400W motor and a 30-liter container, making it suitable for demanding cleaning tasks in workshops or home environments.

Vacuum cleaner components diagram
Vacuum cleaner components diagram

Safety Instructions

  • Always check that the power supply matches the voltage on the rating plate.
  • Do not use the machine to pick up burning or smouldering debris, or explosive/flammable substances.
  • Keep body parts away from the vacuum opening during operation.
  • When picking up liquids, ensure the correct filter is installed and do not connect electrical equipment to the power socket.

Setup and Operation

Before first use, assemble the trolley wheels by securing the axle at the rear and pressing the swivel casters into the front holes. For dry vacuuming, ensure the dust bag is installed. For liquid vacuuming, remove the dust bag and install the provided foamed plastic filter.

The vacuum features an integrated electronic power socket for connecting power tools. When a tool is connected, the vacuum automatically switches on and off in sync with the tool. The maximum power rating for connected tools is 2000W.

Cleaning and Maintenance

  • After dry use: Remove, empty, or replace the dust bag.
  • After wet use: Remove the foamed plastic filter, rinse with water, and allow it to dry thoroughly.
  • Empty the container after every use, especially after picking up liquids, and allow it to dry completely.
  • Regularly clean the motor housing and exhaust outlet with a non-fluffy cloth or brush.

Technical Data

  • Voltage: 230V / 50Hz
  • Power Rating: 1400W
  • Max Socket Power: 2000W
  • Suction Power: 19 kPa
  • Container Capacity: 30 Liters
  • Weight: 10.5 kg

Disposal

This product must be disposed of in accordance with local environmental regulations. In EU countries, do not dispose of this appliance with household waste; it must be collected separately for environmentally friendly recycling.
