James Martin Vanities 36" Castilian Vanity Specification Sheet
Quick guide and technical specifications for the James Martin Vanities 36" Castilian Vanity (models 160-V36-ACG and 160-V36-EG). Includes detailed dimensions, rough-in requirements, material information, and hardware details.
Table of contents
Quick Guide and Specifications
This document provides the technical specifications and dimensional data for the James Martin Vanities 36" Castilian Vanity. It is designed to assist with planning bathroom installations, plumbing rough-ins, and verifying space requirements.
Product Overview
The Castilian vanity is a floor-standing unit constructed from high-quality materials including Soft Maple, Yellow Poplar, and Red Oak veneers. It features a single drawer with English dovetail joinery and soft-close glides.
- Installation Type: Floor standing.
- Features: Soft-close glides, adjustable levelers, and aluminum laminate drawer liners.
- Included: Cabinet only. Optional 3cm vanity tops and sinks are available separately.
- Hardware: Zinc alloy pulls (Antique Bronze for ACG model, Satin Nickel for EG model).
Dimensions and Rough-In
Ensure your bathroom space accommodates the following dimensions:
- Overall Width: 34-3/4"
- Overall Depth: 22-7/8"
- Overall Height: 32-5/8"
- Rough-In Height: 21-1/2"
- Drain Hole Size: 1-3/4"
Installation Notes
The unit includes adjustable levelers to ensure stability on uneven floors. Plumbing rough-in should be planned according to the 21-1/2" height requirement. Please refer to the manufacturer's website for specific installation instructions regarding the optional vanity top and sink.
Manufacturer information
James Martin Vanities
Practical help
Before use
- Verify the rough-in height of 21-1/2" before plumbing installation.
- Ensure the floor area is level to utilize the adjustable levelers.
- Confirm the 34-3/4" width fits your designated bathroom space.
- Check that your sink drain is compatible with the 1-3/4" drain hole size.
Specs in practice
- Rough-In Height
- The required height from the floor for plumbing connections.
- Drain Hole Size
- The diameter required for the sink drain assembly.
- Installation Type
- Floor standing unit requiring no wall mounting.
