LANCOM 1780EW-4G+ High Performance Mobile VPN Router

Product Overview

The LANCOM 1780EW-4G+ is a high-performance mobile VPN router designed for robust connectivity. It features a fanless, durable synthetic housing suitable for desktop or wall-mounted installation. The device supports cellular networks (LTE/UMTS), WLAN, and wired Ethernet connections, making it a versatile solution for secure networking.

Installation and Setup

Before starting, ensure the power plug is easily accessible. For desktop use, attach the provided adhesive rubber footpads. If wall-mounting, use the supplied drilling template. Keep all ventilation slots clear to prevent overheating.

• Power: Connect the power adapter and secure the bayonet connector by turning it 90 degrees clockwise.
• Antennas: Attach the supplied cellular and WLAN antennas while the device is switched off to prevent damage to the modules.
• SIM Card: Insert the SIM card into the slot until it clicks. Only insert or remove the SIM card when the device is powered off to avoid damaging the 4G module.
• Interfaces: Use the provided cables to connect your WAN modem to the ETH2 interface (green connectors) and your PC or switch to the ETH1 interface (kiwi-colored connectors).

LED Status Indicators

The device features comprehensive LED indicators to monitor system health:

• Power: Indicates device status, pairing, and cloud management connectivity.
• WLAN: Shows Wi-Fi network activity and signal strength.
• 4G: Displays cellular network status, data transmission, and SIM card errors.
• SIGNAL: Provides visual feedback on cellular signal strength.
• ETH: Indicates network device attachment and data traffic.
• VPN: Shows the status of active VPN connections.

Technical Specifications

The router operates on a 12 V DC power supply with a consumption of approximately 13 W. It supports a wide range of cellular bands (LTE Advanced, UMTS, HSxPA, HSPA+) and includes two Ethernet ports (10/100/1000 Base-TX). The device is designed for temperatures between 0-35 °C (up to 40 °C when wall-mounted).

Safety and Maintenance

Operate the device only with the professionally installed power supply provided. Do not place objects on top of the router. The device contains no user-serviceable parts and relies on a fanless design for high reliability. Ensure compliance with local regulations regarding antenna gain and transmission power when using external antenna systems.
