Matco Tools 16V Long Reach Ratchet

Name: Matco Tools 16V Long Reach Ratchet
Brand: Matco Tools

Professional 16V Infinium Lithium-Ion long reach ratchets available in 1/4" and 3/8" drive sizes, featuring high torque capacity and durable design.

Table of contents

Product Overview

The Matco Tools 16V Long Reach Ratchet is a professional-grade cordless power tool designed for efficient removal and installation of threaded fasteners. Available in both 1/4" (MCL1614LR) and 3/8" (MCL1638LR) drive configurations, these tools feature a 16V Infinium Lithium-Ion battery system, a captured head design with a retaining clip, and an integrated grease fitting for easy maintenance.

Technical Specifications

Battery Type: 16V Infinium Lithium-Ion
Free Speed: 330 RPM (1/4") / 310 RPM (3/8")
Maximum Torque: 35 ft. lbs.
Manual Torque Withstand: 55 ft. lbs. (1/4") / 155 ft. lbs. (3/8")
Weight with Battery: 3 lbs. (1/4") / 3.4 lbs. (3/8")
Head Width: 1-1/4"

Safety Information

Always wear appropriate personal protective equipment, including safety goggles, hearing protection, and dust masks when operating power tools. Be aware that power tools can create sparks and dust containing harmful chemicals. Ensure the work area is well-lit and free of clutter. Never exceed the manual torque rating of 60 ft. lbs. to avoid tool damage. Keep hands and hair away from rotating parts and always disconnect the battery before making adjustments or storing the tool.

Operation

To install the battery, align it with the tool housing and push until it clicks. To remove, depress the tabs on both sides and pull downward. Ensure the switch is in the "off" position before battery insertion or removal. The tool is designed for hand-held operation; do not force the tool or leave it running unattended. Use the simplest possible tool-to-socket connection to maximize power efficiency.

Maintenance and Care

Repairs and maintenance must be performed only by authorized Matco service centers. Keep the tool and battery away from extreme temperatures and conductive objects to prevent short circuits. Recharge batteries only with the designated Matco charger. For optimal battery life, store at approximately 50% charge and avoid exposing the battery to shock, vibration, or contaminants.

Troubleshooting and Disposal

If the tool fails to operate, check the battery connection and charge level. Do not attempt to disassemble the tool or battery pack. Dispose of worn-out batteries through proper authorities; do not incinerate, as they may explode.
