User Manual for Princess 01.212094.01.001 Blender

Quick guide from the manual

This blender is designed for household use. It features 4 automatic functions and manual speed control. Always ensure the jug and lid are correctly positioned before operation, as the device will not activate otherwise. If the motor stops during operation, switch off, unplug, and allow it to cool for at least 30 minutes.

Safety instructions

• Do not immerse the cord, plug, or motor unit in water or other liquids.
• The chopping blades are very sharp; handle with extreme care during cleaning and emptying.
• This appliance is not intended for use by children under 8 years old.
• Always disconnect the device from the power supply if left unattended and before assembly, disassembly, or cleaning.
• Do not operate the blender continuously for more than 3 minutes.

Parts description

• 1. Measuring cup
• 2. Jug lid
• 3. Safety lock
• 4. Handle
• 5. Jug
• 6. Blades
• 7. Motor base
• 8. Speed dial
• 9. Smoothie button
• 10. Auto Clean button
• 11. Ice Crush button
• 12. Pulse button

Operation

Attaching and detaching the jug

To detach, hold the handle and gently turn the jug anti-clockwise. To attach, align the mounting pins on the jug base with the motor base and turn the jug clockwise until it locks into position.

Attaching and detaching the jug lid

Hold the lid vertically over the jug and place the spout on the lid under the spout on the jug. Press the lid down until the safety latch clicks on the handle. To detach, release the safety latch and pull the lid upwards.

Blending

Plug in the appliance and turn the speed dial to [ON]. Choose the desired function (Smoothie, Ice Crush, Extract) or use the speed dial for manual control between [MIN] and [MAX]. You can add ingredients through the centre opening while blending by removing the measuring cup.

Auto-Clean function

1. After blending, reassemble the jug to the base and pour about 400-500 ml of warm water into the jug.
2. Turn the speed dial to [ON].
3. Press the [AUTO-CLEAN] button.
4. The operation will begin and stop automatically when complete.
5. Turn the speed dial to [OFF], unplug the appliance, and remove the jug for final cleaning.

Cleaning and maintenance

Unplug the appliance and allow it to cool before cleaning. Clean the exterior with a damp cloth. Do not use abrasive cleaners or steel wool. All parts except the motor unit are dishwasher safe. Store the appliance with the jug lid slightly open to prevent odors.
