Bosch UniversalHedgeCut 18V Cordless Hedge Trimmer User Manual
Quick guide for the Bosch UniversalHedgeCut 18V series cordless hedge trimmer, covering assembly, operation, maintenance, and troubleshooting.
Table of contents
Quick guide from the manual
This document provides essential information for the safe and efficient operation of the Bosch UniversalHedgeCut 18V series hedge trimmer. Always ensure the battery is removed before performing any maintenance or adjustments. The tool is designed for trimming hedges and bushes in domestic gardens.
Device description
The hedge trimmer features a dual-handle design with safety switches on both handles, which must be pressed simultaneously for operation. It includes an anti-blocking mechanism to prevent stalling in tough material.
Operation
To start the tool, insert the battery until it clicks, then press the front switch and the rear handle switch simultaneously. To stop, release either or both switches. For best results, cut the sides of the hedge first, then the top, moving in the direction of growth.
Battery maintenance
Store the battery and tool within a temperature range of -20 °C to 50 °C. Do not leave the battery in the product under direct sunlight. Clean ventilation slots occasionally with a soft, dry brush.
Safety
Do not use the tool in bad weather, especially if there is a risk of lightning. Keep all power cords away from the cutting area. Always wear eye and ear protection. The tool contains magnets; keep away from medical implants like pacemakers.
Maintenance
Keep the product clean for safe operation. Lubricate the blade bar with maintenance spray before each use. The hedge trimmer, blades, and battery cannot be repaired by the user; contact Bosch customer service for any defects.
Manufacturer information
Bosch
Practical help
Common problems
Hedge trimmer does not operate
Check if the battery is discharged or not fully connected.
Cutting blade becomes hot
The blade is blunt, has dents, or lacks lubrication. Sharpen or inspect the blade and apply lubricant spray.
Cutting time per battery charge is too low
Clean the blade, improve cutting technique, or ensure the battery is fully charged.
Before use
- Inspect the hedge for wires or foreign objects.
- Check that all handles and guards are properly fitted.
- Lubricate the blade bar with maintenance spray.
- Ensure the battery is fully charged.
- Wear protective gloves, eye protection, and sturdy footwear.
Specs in practice
- Stroke rate at no-load
- The number of cutting strokes per minute without load (2800 min-1).
- Cutting length
- The effective length of the blade (50 cm or 55 cm depending on model).
- Tooth opening
- The maximum diameter of branches the blade can cut (20 mm or 22 mm).
Images and diagrams
- Figure A: Overview of components including handles, switches, hand guard, and blade.
- Figure B: Battery insertion and removal procedure.
- Figure D: Correct two-handed operation for starting.
- Figure F: Proper cutting technique for hedges.
Model compatibility
- Compatible with Bosch 18V PBA series batteries (1.5 Ah to 6.0 Ah).
- Use only with recommended Bosch chargers (AL 1810 CV, AL 1830 CV, AL 1880 CV, AL 1844 CV).
