User Manual for Brass Monkey 138L Upright Fridge GH1662

Quick guide from the manual

This guide provides essential information for the Brass Monkey 138L Upright Fridge (GH1662). Before first use, ensure the unit is placed on a level surface and left for at least 6 hours before turning it on. Always remove the packaging plate from under the bottom of the refrigerator before use. The unit operates on 12V/24V DC power.

Safety Warnings

• Do not operate the appliance if it is visibly damaged.
• Keep ventilation openings free of obstacles.
• Do not use electrical appliances inside the food storage compartments.
• The appliance must be kept horizontal when running; tilt angle must be less than 5° for long-term use and less than 45° for short-term use.
• Do not use sharp tools to defrost.
• Disconnect power supply before cleaning and maintenance.

Installation and Preparation

Proper placement is crucial for performance and longevity:

• Location: Place in a dry, cool, and ventilated area away from heat sources and direct sunlight.
• Clearance: Allow 30cm at the top, 10cm on the sides, and 20cm at the back for air circulation.
• Surface: Ensure the floor is flat and strong. If not level, adjust the feet to prevent vibration and noise.
• Carpet: If placing on carpet, use wooden boards underneath to prevent discoloration from compressor heat.

Operation and Temperature Control

The refrigerator features a thermostat to control internal temperature:

• Setting: Use the thermostat button (numbered 1-7).
• Recommendation: Setting 3 to 4 is recommended for a balance between freshness and energy saving.
• Quick-freezing: Set the control to 6-7 for rapid cooling, then return to the normal position once finished.
• Stopping: A setting of 0 will force the refrigerator to stop.

Food Storage

• Freezer (Below -18°C): Suitable for meat, fish, and making ice. Wrap meat tightly. Do not store fruit/vegetables here to avoid freeze-drying.
• Refrigerator (0°C to 5°C): Suitable for eggs, butter, milk, and drinks. Use the crisper for fruit and vegetables.
• General: Allow hot food to cool before storing. Use zip-lock or vacuum bags to save space and allow air circulation.

Cleaning and Maintenance

• Cleaning: Unplug the unit. Use a soft cloth with warm water and neutral detergent. Wipe dry. Do not submerge in water or use abrasive agents.
• Defrosting: If frost forms, switch off the device, remove contents, keep the lid open, and drain water from the bottom hole.
• Storage: If not used for an extended period, turn off, clean, dry, and leave the lid slightly open to prevent odors.

Troubleshooting

• Refrigerator does not work: Check power switch, plug connection, fuse, and power supply.
• Compartments too warm: Check if the lid is opened frequently or if a large amount of hot food was recently stored.
• Food is frozen: Temperature is set too low.
• Water flow noise: This is normal, caused by the flow of refrigerant.
• Waterdrops on casing: Normal condensation on cold surfaces.

Technical Specifications

• Rated Voltage: DC 12/24V
• Power Consumption: 60W
• Capacity: 138L
• Noise Emission: ≤45dB
• Temperature Range: Fridge 0°C to +5°C; Freezer -18°C
• Dimensions: 455 x 455 x 1300 mm
• Weight: 33kg
