FLEX DW 45 18.0-EC Cordless Drywall Screwdriver

Product Description

The FLEX DW 45 18.0-EC is a high-performance cordless drywall screwdriver engineered for professional use in industry and trade. It is specifically designed for efficient fastening of drywall, chipboard, and fiberboard panels to wood or metal structures. The tool is compatible with the M-DW screw magazine, which allows for rapid, continuous screw driving, significantly increasing productivity in interior construction tasks.

Technical Specifications

• Machine Type: Cordless drywall screwdriver
• Battery: AP 18.0/2.5 or AP 18.0/5.0
• No-load speed: 0-4500 min-1
• Max. torque (Soft/Hard): 6/28 Nm
• Tool holder: 1/4" (6.35 mm) hexagon socket
• Weight (without battery): 0.98 kg

Safety Information

WARNING! Before using the power tool, read and follow the operating instructions, the enclosed "General safety instructions" (leaflet no. 315.915), and local accident prevention regulations. The tool must only be used as intended and in perfect working order. Faults that impair safety must be eliminated immediately.

Operation

Before starting work, ensure the battery is charged and properly inserted. The tool features an adjustable depth stop to ensure consistent screw depth. When the preset depth is reached, the drive disengages, preventing damage to the workpiece. For rapid fastening, the M-DW screw magazine can be attached. Always ensure the direction of rotation selector is in the middle position before performing any maintenance or tool changes.

Maintenance and Care

Regularly clean the power tool and ventilation slots. Periodically blow out the housing interior, motor, and screw magazine with dry compressed air. Always wear safety goggles when cleaning with compressed air. Repairs must be carried out exclusively by an authorized customer service center.

Disposal

Do not dispose of power tools in household waste. In accordance with European Directive 2012/19/EU, used power tools must be collected separately and recycled in an environmentally friendly manner. Batteries must also be recycled according to Directive 2006/66/EC.
