Avantco 178SSUC48FHC 48" Undercounter Freezer

Product Overview

The Avantco 178SSUC48FHC is a high-performance 48-inch undercounter freezer designed for demanding commercial kitchen environments. It combines a robust 430 type stainless steel exterior with a durable 304 type stainless steel interior, ensuring long-lasting reliability and ease of cleaning. The unit provides 11.2 cubic feet of storage space, organized by two epoxy-coated steel shelves capable of holding up to 90 lbs each.

Technical Specifications

• Dimensions: 47 1/4" W x 29 1/2" D x 35 1/4" H
• Temperature Range: -8 to -1 degrees Fahrenheit
• Refrigerant: R-290 (environmentally friendly)
• Electrical: 115V, 60Hz, 1.91 Amps, 1/2 HP
• Capacity: 11.2 cu. ft.
• Shelving: 2 adjustable shelves

Operation and Maintenance

This freezer is equipped with a digital temperature controller for precise monitoring and an automatic defrost function to maintain optimal performance. The foamed-in-place polyurethane insulation effectively traps cold air, preventing ambient heat from entering the cabinet. The unit is mounted on 2 1/2-inch casters, which facilitate easy movement for cleaning and maintenance while ensuring the work surface remains at an ADA-compliant height.

Safety and Compliance

The unit utilizes R-290 hydrocarbon refrigerant, which has an ozone depletion potential of 0 and a low global warming potential, making it an environmentally responsible choice. Please note that this product contains chemicals, including lead, which are known to the State of California to cause cancer and birth defects or other reproductive harm. Always ensure the unit is connected to a proper 115V electrical supply as specified in the technical data.
