Bright Starts Toucan Tango Bouncer Instruction Manual

Comprehensive user guide for the Bright Starts Toucan Tango Bouncer (Model 10589-ES), covering assembly, safety warnings, battery installation, operation, and maintenance.

Table of contents

Product Overview

The Toucan Tango Bouncer is designed to provide a comfortable and soothing environment for infants. It features a vibration unit and music playback to help calm the baby. The bouncer is lightweight and portable, making it easy to move around the home.

Safety Warnings

Fall Hazard: Babies have suffered skull fractures falling from bouncers when not used properly. Never leave the child unattended. Use the bouncer only on the floor and never on elevated surfaces. Never lift or carry the baby while in the bouncer, and never use the toy bar as a handle.

Suffocation Hazard: Babies have suffocated when bouncers tipped over on soft surfaces or were used as sleep products. Never use on a bed, sofa, cushion, or other soft surface. This product is not safe for sleep. If the baby falls asleep, move them immediately to a firm, flat sleep surface like a crib or bassinet.

Usage Limits: Always use the restraint system and adjust it to fit snugly. Stop using the bouncer as soon as the baby starts trying to sit up or reaches 20 lbs (9 kg), whichever comes first.

Assembly and Setup

The bouncer requires adult assembly. Ensure all parts are present and undamaged before beginning. The frame components snap together, and the seat pad is secured with buckles and hook-and-loop fasteners. The toy bar attaches to the top of the frame to provide entertainment.

Exploded view of bouncer components
Exploded view of bouncer components

Battery Information

The music and vibration unit requires (3) size C/LR14 (1.5V) alkaline batteries (not included). Always install batteries with the correct polarity. Do not mix old and new batteries or different types. Remove batteries if the product will be stored for a long period. Weak batteries may cause erratic operation, such as distorted sound or failed motor functions.

Care and Cleaning

To maintain the bouncer, remove the seat pad from the frame. The seat pad and headrest are machine washable in cold water on a gentle cycle; do not bleach and tumble dry on low heat. The toy bar, toys, and metal frame should be wiped clean with a damp cloth and mild soap. Do not immerse the toy bar or vibration unit in water.

Manufacturer information

Bright Starts

Brand profile

Practical help

Common problems

Distorted sound, dimming lights, or slow motor

Replace all batteries with a fresh set of the same type.

Vibration function stops working

The vibration function automatically turns off after 30 minutes; restart it using the switch.

Before use

  • Ensure all parts are present and not damaged.
  • Check that the bouncer is placed only on the floor.
  • Verify the baby is under 20 lbs (9 kg) and cannot sit up.
  • Ensure the restraint system is adjusted to fit the baby snugly.
  • Confirm the vibration/music unit is securely attached.
  • Check that all frame connections are locked in place.

Specs in practice

Weight Limit
Maximum 20 lbs (9 kg) or when the baby starts trying to sit up.
Vibration Auto-off
The vibration function automatically shuts off after 30 minutes.

Images and diagrams

  • Page 15 shows the exploded view of all components.
  • Page 16 illustrates the frame assembly process.
  • Page 18-19 details the battery installation steps.
  • Page 23 demonstrates how to secure the baby using the seat restraint.

Model compatibility

  • Do not use the bouncer as a sleep product.
  • Do not use on elevated surfaces.
  • Do not use as an infant carrier for travel.
