ECO-WORTHY 100W 18V Foldable Solar Panel
A portable, high-efficiency 100W monocrystalline solar panel designed for off-grid power, featuring adjustable kickstands, IP65 waterproofing, and versatile DC adapter compatibility for charging 12V batteries and power stations.
Table of contents
Product Overview
The ECO-WORTHY 100W 18V foldable solar panel is a versatile and portable power solution designed for outdoor enthusiasts and off-grid applications. Whether you are camping, hiking, or need a reliable power source for your caravan, boat, or garden shed, this panel provides efficient energy conversion. Its foldable design allows it to be packed down to the size of a briefcase, making it easy to transport and store when not in use.
Key Features and Performance
This solar module utilizes high-efficiency Class A monocrystalline solar cells to ensure maximum power output. A standout feature is the integrated kickstand system, which allows users to adjust the panel's tilt angle between 30 and 40 degrees. This adjustability helps optimize the angle relative to the sun, potentially increasing irradiance capture by up to 25 percent compared to flat-mounted panels. The unit is built to withstand outdoor conditions with an IP65 waterproof rating for the junction box, ensuring durability against the elements.
Technical Specifications
The panel is engineered for 12V systems, offering a rated power of 100W. Key electrical parameters include a maximum power voltage (Vmp) of 18V and an open circuit voltage (Voc) of 21.6V. The short circuit current is rated at 5.9A, with a maximum operating current of 5.6A. The panel is compatible with various battery types, including lithium, gel, and lead-acid batteries. It also features a built-in diode to prevent reverse current flow, protecting your battery during low-light conditions.
Setup and Usage
Setting up the panel is straightforward. The package includes a 3-meter extension cable with a 5.5x2.1mm DC connector, along with a bag of various DC adapters to ensure compatibility with approximately 95 percent of portable power stations on the market. To use, simply unfold the panel, deploy the kickstands to the desired angle, and connect the appropriate adapter to your device or battery system. Ensure the panel is placed in an area with direct sunlight and no shading for the best performance. The system is designed for ease of use, allowing for quick deployment in various environments such as farms, homes, or remote campsites.
Practical help
Common problems
Low power output
Ensure the panel is placed in direct sunlight without shading and that the tilt angle is adjusted using the kickstands for optimal irradiance.
Incompatibility with power station
Use the included bag of DC adapters or the 5.5x2.1mm to MC4 adapter to match the input port of your specific power station.
Before use
- Check that the solar panel surface is clean and free of debris.
- Verify that the kickstands are securely locked at the desired angle.
- Ensure the extension cable is firmly connected to the junction box.
- Select the correct DC adapter for your specific power station or battery.
- Confirm the panel is positioned in an area with unobstructed sunlight.
Specs in practice
- Rated Power (100W)
- The maximum power output the panel can generate under standard test conditions.
Images and diagrams
- The module diagram shows the physical dimensions of the panel in both extended and folded states.
- The diagram highlights the location of the junction box and the output cable connection point.
- The kickstand mechanism is illustrated to show how the panel tilts to capture more sunlight.
Model compatibility
- Compatible with lithium, gel, and lead-acid 12V batteries.
- Includes adapters for 95% of portable power stations.
- Features a built-in diode to prevent reverse current.
