Einhell TP-CW 18/750-C Li BL Battery Impact Driver

Product Description

The Einhell TP-CW 18/750-C Li BL is a high-performance cordless impact driver designed for demanding automotive and construction tasks. It features a brushless motor for increased power and longer runtime. The tool is equipped with a 1/2" external square drive mount and offers four distinct operating modes, including an 'Autostop' function that prevents over-tightening or accidental dropping of nuts during loosening.

Technical Data

• Voltage: 18 V DC
• Idling speed: 0-2400 min-1
• Blow rate: 0-3300 min-1
• Tool chuck: 1/2" (12.7 mm)
• Weight: 1.8 kg

Safety

Always wear appropriate personal protective equipment, including ear protection, safety goggles, and a dust mask when working with materials that generate dust. Do not work on asbestos-containing materials. Ensure the battery is stored in a dry environment between +10°C and +40°C and kept at least 40% charged.

Operation

Before starting, ensure the battery is charged using the compatible charger. The tool features a direction changeover switch for clockwise/counter-clockwise rotation and a selector switch for four operating modes (1, 2, 3, and A). The 'Autostop' (A) mode automatically stops the tool when resistance is detected (tightening) or when resistance is no longer detected (loosening). Always ensure the direction switch is in the center position when changing tools or performing maintenance.

Maintenance and Troubleshooting

Keep air vents and the motor housing free of dust and dirt. Clean the tool regularly with a damp cloth and mild soap. Do not use solvents or cleaning agents that could damage plastic parts. If the tool fails to operate, check the battery charge status and ensure the charger is functioning correctly. For detailed error codes, refer to the charger indicator table in the manual.

Disposal

Dispose of the tool, battery, and accessories in accordance with local environmental regulations. Do not discard in household waste.
