Owner's Manual for Evolur 0123R1-613 Holland Upholstered Swivel Glider

Quick guide from the manual

This document provides essential assembly and maintenance instructions for the Evolur 0123R1-613 Holland Upholstered Swivel Glider. Always assemble the product on a soft, level surface to prevent damage. Do not use power drills or drivers during assembly. The maximum weight capacity is 108 kg (240 lbs).

Safety information

• Adult assembly is required.
• Small parts present a choking hazard before assembly.
• Do not use the glider if any parts are missing, damaged, or broken.
• Keep hands and feet clear of the mechanism; only the occupant should operate it.
• When not in use, leave the chair in an upright and closed position.
• Periodically check all connecting points to ensure they remain secure.

Assembly instructions

1. Base Setup: Place the glider on a soft, level surface. Carefully cut the straps wrapped around the metal swivel mechanism underneath the seat.
2. Back Seat Setup: Align the metal channel on the backrest with the metal prongs on the seat frame. Slide the backrest onto the prongs until it clicks and locks. Secure the backrest using the provided washers and screws with the included Allen key. Pull the backrest upward to verify it is fully secured.
3. Cushion Assembly: Place the cushion on the seat, resting it against the backrest.

Furniture care instructions

• Protect surfaces from hot or extremely cold items.
• Keep fabric away from pens, markers, crayons, and scented items like potpourri.
• Clean only with mild, water-free solvents. Never use water or harsh detergents.
• Do not use bleach or dry clean individual parts.
• Do not spray cleaners directly onto the furniture.
• Lift the chair slightly when moving it on carpeting to prevent damage to the swivel mechanism.

Contact information

For assistance or replacement parts, visit www.evolurbaby.com/help or contact Evolur Inc via email at [email protected].
