User Manual for Furrion 18 Cu.ft. French Door Refrigerator

Quick Guide from the Manual

This refrigerator is designed for use in recreational vehicles and requires a 110V power source. Before first use, ensure the unit has been in an upright position for at least one hour to allow the refrigerant to settle. The refrigerator must be installed on a level, solid surface with adequate ventilation (minimum 1 inch clearance on sides, back, and top). Always disconnect the power supply before performing any maintenance or troubleshooting.

Safety Instructions

• Electric Shock Hazard: Do not open the unit. Dangerous voltage is present inside.
• Keep ventilation openings clear of obstructions.
• Do not use mechanical devices to accelerate defrosting.
• Do not damage the refrigerant tubing.
• Children should be supervised to ensure they do not play with or crawl inside the refrigerator.
• Before disposing of an old refrigerator, remove the doors and electrical wiring to prevent entrapment.

Installation

The refrigerator is not designed for recessed installation. Ensure the floor is level and solid. A minimum spacing of 1 inch (25mm) is required on both sides, the backside, and the top. The unit must be fixed to the RV cabinetry using the provided screws or similar Pan Head type screws. Ensure the refrigerator is leveled using the front leveling feet.

Water Supply Connection

Access to a cold water line with pressure between 20 and 120 psi is required. Connect the supply line to the inlet valve on the refrigerator using a 1/4" fitting. Flush the line until water is clear before making the final connection.

Ice Maker

The ice maker produces approximately 3.5 lbs of ice per day. It will begin making ice 12 to 24 hours after the refrigerator is turned on. To turn the ice maker on or off, press the power button for 2 seconds. If the unit is stored for a long period, clean the ice maker by running fresh water through it and discarding the first few batches of ice.

Functions and Operation

The refrigerator features an LED display with electronic controls. Use the "Fridge" and "Freeze" buttons to adjust temperatures. The "Select" button allows you to toggle between Quick Freezing and Smart modes. In Smart mode, temperatures are regulated automatically based on environmental changes.

Maintenance and Cleaning

Clean the interior at least once a month using a soft towel or sponge with warm water or neutral detergent. Do not use harsh chemicals, abrasive brushes, or corrosive cleaners. If the LED light is damaged, it should be replaced by a professional. The refrigerator features an automatic defrosting function, so no manual defrosting is required.

Troubleshooting

If you encounter issues, check the following:

• Button failure: Check if the control board is in lock mode.
• Compressor won't start: Charge the RV batteries by connecting to shore power.
• Noise: Normal sounds include gurgling or louder operation during the first use.
• Compressor hot: Normal during operation; do not touch.
• Ice maker not working: Ensure the switch is ON, the water valve is open, and the freezer door is closed.

Specifications

• Total Capacity: 18 Cu.ft.
• Rated Voltage: 110V
• Refrigerant: R600a
• Temperature Range: Refrigerator: 32°F to 43°F; Freezer: -10°F to 5°F
• Defrost: Automatic
