User Manual for Furrion 100W Kickstand Solar Panel FSPK10MWT-BL
Quick guide for the Furrion 100W Kickstand Solar Panel (FSPK10MWT-BL). Includes setup, battery type selection, maintenance, and technical specifications.
Table of contents
Manual images
Click an image to enlargeQuick Guide from the Manual
The Furrion 100W Kickstand Solar Panel is a portable, monocrystalline solar solution designed for off-grid use. This manual covers the setup, battery type configuration, and maintenance required to keep the panel operating efficiently.
Safety Precautions
- Do not use near open flammable sources.
- Do not sit on or hang items from the product.
- Do not set up on elevated surfaces (roofs, tables) or ladders.
- Do not set up on uneven surfaces or in standing water.
- Do not place wiring in travel paths (walking or vehicle areas).
- Do not place the panel in shaded areas (RV, trees, etc.).
- Only use as intended; modifications will void the warranty.
Setup and Operation
The solar panel is ready to use out of the box. To set it up:
- Unfold the panel.
- Ensure the panel has stable footing on a flat, even surface.
- Lock the folding legs in position using the turn knob.
- Plug the panel into your Furrion RV solar inlet, Furrion PowerStation, or Furrion eRove electric cooler.
Battery Type Selection
To select the correct battery type for the charge controller:
- Press the button for 3 seconds. The LED will begin to flash, indicating the mode can be changed.
- Press the button to cycle the LED number from 1 to 4.
- When the desired battery type number appears, wait until the LED stops flashing or press the button again for 3 seconds to complete the setting.
Battery Types:
- 1: Sealed lead-acid batteries
- 2: GEL lead-acid batteries
- 3: Flooded lead-acid batteries
- 4: Lithium iron phosphate batteries
Handling and Routine Maintenance
- Always carry the product by the lifting handle.
- Always protect the glass surface when handling or storing.
- Always keep the glass clean to maximize efficiency.
- Always check wiring and connector quality.
- Clean using only warm soapy water and a clean cloth. Never use acidic solutions.
Specifications
Mechanical:
- Solar Cell Type: Monocrystalline
- Product Size: 34 1/16" x 26 1/16" x 1 3/8" (870mm x 670mm x 35mm)
- Weight: 17.6lbs (8.0kg)
- Cable Length: 181 1/8" (4.6m)
- Junction Box: IP65 rated (dust proof, water resistant)
Working:
- Max. Power (Pmax): 100W
- Rated Voltage (Vmpp): 17V
- Rated Current (Impp): 5.9A
- Open Circuit Voltage (Voc): 20.9V
- Short Circuit Current (Isc): 6.13A
Manufacturer information
Furrion
Practical help
Common problems
Panel not charging
Ensure the panel is in direct sunlight and not shaded by trees, RV structures, or other obstructions.
Unstable panel
Ensure the panel has stable footing and the folding legs are locked in position with the turn knob.
Before use
- Ensure the panel is placed on a flat, even surface.
- Check that the panel is not in a shaded area.
- Verify that wiring is not in a travel path.
- Ensure the panel has stable footing.
- Check that the folding legs are locked in position.
Specs in practice
- Max. Power (Pmax)
- The maximum power output of the panel under standard test conditions (100W).
- Rated Voltage (Vmpp)
- The voltage at which the panel produces maximum power (17V).
- Rated Current (Impp)
- The current at which the panel produces maximum power (5.9A).
- Open Circuit Voltage (Voc)
- The maximum voltage the panel can output when not connected to a load (20.9V).
Images and diagrams
- The setup diagram illustrates how to unfold the solar panel and position it for optimal sun exposure.
- The dimensions diagram provides the physical measurements of the panel (870mm x 670mm x 35mm).
Model compatibility
- Compatible with Furrion RV solar inlet.
- Compatible with Furrion ePod battery.
- Compatible with Furrion eRove ecosystem.
