Installation Guide for Hokku Designs Ceiling Light
Step-by-step installation guide for your Hokku Designs ceiling light. Learn how to securely mount the bracket, connect wiring, and assemble the glass shade and decorative components.
Table of contents
Quick guide from the manual
This document provides the essential steps for the safe installation and assembly of your Hokku Designs ceiling light. Ensure the power is turned off at the circuit breaker before beginning any electrical work. The installation requires basic tools to secure the mounting bracket to the junction box and connect the electrical wires.
Installation and Assembly
- Secure the mounting bracket (1) to the junction box using the provided screws (2).
- Connect the main house wires to the lamp body wires using the twist-on wire connectors (3). Ensure the ground wire (green) is properly connected.
- Fasten the ceiling canopy (4) to the mounting bracket using the decorative nuts (5).
- Install the light bulb (6). Note that the bulb is not included with the fixture.
- Attach the metal washer and rubber washer (7) onto the central stem.
- Carefully install the glass lampshade (8).
- Secure the glass shade by mounting the rubber washer, metal washer, and nut (9).
- Attach the decorative cover (10).
- Tighten the decorative finial (11) to complete the assembly.
Safety
Always ensure the electrical supply is disconnected before starting the installation. If you are not familiar with electrical wiring, it is recommended to consult a qualified electrician to ensure the fixture is installed in accordance with local building and electrical codes.
Practical help
Common problems
Fixture does not light up after installation
Verify that the bulb is properly seated and that the wire connections (Neutral, Positive, and Ground) are secure and correctly matched.
Glass shade feels loose
Ensure the rubber and metal washers are placed correctly on both sides of the glass and that the final nut (9) is tightened sufficiently.
Before use
- Turn off power at the main fuse box or circuit breaker.
- Ensure you have a compatible light bulb (not included).
- Verify that the junction box is capable of supporting the weight of the light fixture.
- Check that all parts listed in the assembly diagram are present.
Specs in practice
- Twist-on connector (3)
- Used to safely join the house supply wires to the fixture wires.
- Decorative finial (11)
- The final cap that secures the assembly and provides a finished look.
Images and diagrams
- The diagram illustrates the vertical assembly sequence from the ceiling junction box down to the decorative finial.
- It highlights the correct order of washers and nuts required to support the glass lampshade.
Model compatibility
- The fixture requires a light bulb which is not included in the package.
- Installation must be performed on a standard electrical junction box.
