Husqvarna WT 10MP Pressurized Water Tank
The Husqvarna WT 10MP is a professional-grade pressurized water tank designed to supply water for dust suppression in applications such as drilling, concrete sawing, and grinding.
Table of contents
Product Description
The Husqvarna WT 10MP is a pressurized water tank designed for professional use. It provides a reliable water supply for dust suppression during construction tasks such as drilling, concrete sawing, and grinding. Pressure is generated manually using a built-in pump.
Safety
Warning: This product can be dangerous if used incorrectly. Only trained, healthy, and rested professionals should operate the device. Always avoid ignition sources, protect the unit from frost and ammonia, and never leave the device under pressure when not in use or during transport. The safety valve must never be bypassed or made inoperative.
Operation
To prepare the tank, ensure it is in an upright position. Depressurize the tank by pulling up the red piston pressure gauge. Unscrew the pump, fill the tank with liquid (up to 10 liters), and screw the pump back in. Use the hand pump to build pressure, monitoring the gauge to ensure it does not exceed 3 bar. Connect the hose to your equipment using the plug-in coupling and regulate the flow using the ball valve on your tool.
Maintenance
Regular maintenance is essential for safe operation. After 50 uses or at least once a year, dismantle the pump to grease the O-ring and diaphragm. Clean the discharge filter under running water regularly. If the device fails to build pressure, check that the pump is screwed on tightly and inspect the O-ring and diaphragm for defects.
Manufacturer information
Husqvarna
Practical help
Common problems
No pressure builds up in the device
Ensure the pump is screwed on tightly. If the issue persists, check the O-ring and diaphragm for damage and replace if necessary.
Liquid flows out of the pump
Clean or replace the valve disc.
No pressure indication on the gauge or safety valve blows off too early
The piston pressure gauge is likely defective and needs to be replaced.
Before use
- Visually inspect the tank, pump, hose, and pressure gauge for damage.
- Check all connections between the tank, hose, and plug-in coupling.
- Ensure the pump thread is in good condition.
- Verify the device is in an upright position.
- Ensure the water line or hose does not project into the tank during filling.
Specs in practice
- Max. filling amount
- 10 liters (2.64 gal)
- Max. spraying pressure
- 3 bar (43.5 psi)
- Max. operating temperature
- 40 °C (104 °F)
- Weight when empty
- 2.8 kg (6.16 lb)
Images and diagrams
- The manual includes detailed diagrams on pages 3-5 showing the assembly, pressurization, and maintenance procedures.
- Figure 11 illustrates the pressure gauge and the red line indicating the 3 bar maximum limit.
- Figure 12 shows the connection of the plug-in coupling to the device.
Model compatibility
- Designed for professional use with drills, concrete saws, and grinders.
- Do not use for storage of liquids, drinking water, or as an eyewash.
- Use only original spare and accessory parts.
