User Manual for Imperii 10000mAh Wireless Charger Power Bank
Quick guide for the Imperii 10000mAh Wireless Charger Power Bank. Learn how to charge your devices wirelessly or via cable, understand LED indicators, and follow safety guidelines for optimal use.
Table of contents
Quick guide from the manual
The Imperii 10000mAh Wireless Charger Power Bank allows you to charge devices both wirelessly and via a USB cable. Before first use, ensure the power bank is fully charged. For wireless charging, place your Qi-compatible device in the center of the charging area. If charging via cable, connect your device to the USB output port.
Product Overview
The device consists of the following components:
- Wireless Charging Area: The surface where you place your device for wireless charging.
- Power Button: Used to turn the power bank on.
- Wireless Charging Light: Indicates wireless charging status.
- Micro USB Input: Port for charging the power bank itself.
- USB Output: Port for wired charging of devices.
- Battery Status Indicator: Shows remaining battery capacity.
Charging the Power Bank
To recharge the power bank, connect a Micro USB cable to the input port and connect the other end to a power adapter. The LED indicators will flash while charging and remain solid when fully charged.
Charging Devices
Wireless Charging: Press the power button to turn on the power bank. Place your Qi-compatible device in the center of the wireless charging area. The wireless charging light will turn on.
Wired Charging: Connect your device's charging cable to the USB output port on the power bank. Charging will begin automatically.
Safety and Maintenance
- Do not disassemble or modify the device.
- Keep the device away from water, moisture, and extreme heat.
- Do not place metal objects (like keys or coins) between the device and the charger, as this may cause overheating.
- If the device is not used for a long period, charge it at least once every three months.
Technical Specifications
- Capacity: 10000mAh
- Input: DC 5V/2A
- Wireless Output: 5W
- Wired Output: 5V/2A
- Dimensions: 74 x 133 x 19mm
Manufacturer information
Imperii Electronics
Practical help
Common problems
Device not charging wirelessly
Ensure the device is placed in the center of the wireless charging area and that there are no metal objects or thick cases between the device and the charger.
Power bank not charging
Check that the Micro USB cable is securely connected to both the power bank and the power adapter.
Before use
- Charge the power bank fully before the first use.
- Verify that your mobile device is Qi-compatible for wireless charging.
- Ensure the charging cable is in good condition.
- Remove any metal cases or magnetic attachments from your phone before wireless charging.
Specs in practice
- Capacity: 10000mAh
- The total energy storage capacity of the power bank.
- Wireless Output: 5W
- The standard power delivery rate for wireless charging.
Images and diagrams
- The diagram illustrates the layout of the power bank, highlighting the wireless charging surface, the power button, the LED indicators, and the input/output ports.
Model compatibility
- Wireless charging is only compatible with Qi-enabled devices.
