Simon K45 Italian Bipasso Socket 10/16A

Product Overview

The Simon K45 Italian bipasso socket is a high-quality electrical component designed for reliability and safety. This 10/16A socket features a distinct red finish and is engineered for use within the Simon K45 installation system. It is suitable for a wide range of environments, including residential and commercial wall, floor, ceiling, and furniture installations.

Technical Specifications

This socket is built to meet rigorous standards, ensuring durability and performance. It features a screw-terminal connection system for secure wiring. The device is rated for 10/16A current and has an IP20 protection rating. The material used is high-quality plastic, and it is finished in a RAL 3002 red color. The socket is designed to withstand high temperatures, with a glow wire flammability index (GWFI) of +850 degrees Celsius for 30 seconds, in accordance with IEC 60695-10-2 standards.

Installation and Maintenance

Installation should be performed by qualified personnel. The cable requires a stripping length of 12 mm to ensure a proper connection within the screw terminals. For maintenance, the socket should be cleaned using a soft, dry cloth. It is strictly advised to avoid the use of abrasive cloths or detergents containing chlorine, as these can damage the surface and integrity of the device. If the socket needs to be removed from its housing, this must be done using appropriate tools to prevent damage to the mounting frame or the socket itself.

Compatibility and Integration

The Simon K45 socket is highly versatile and compatible with the full range of Simon K45 installation envelopes. For integration with Simon 500 Cima systems, the socket requires the use of a specific K45 to 500 Cima adapter (reference 50012088-030). This modular design allows for seamless integration into various electrical infrastructure setups, providing a clean and professional finish in any application.
