Singer 168w101 Sewing Machine Parts List
Official parts list and oiling guide for the Singer 168w101 sewing machine. Includes exploded view diagrams and part numbers for maintenance and ordering.
Table of contents
Manual images
Click an image to enlargeQuick guide from the manual
This document serves as a comprehensive parts list for the Singer 168w101 sewing machine. It includes instructions for proper maintenance and part identification.
Oiling instructions
To ensure smooth operation and prevent unnecessary wear of moving parts, the machine requires regular oiling. When in continuous use, apply Singer Type B or Type D oil to all oil holes marked OIL at least twice each day. Type D oil is stainless.
Ordering parts
When ordering parts from this list, please follow these guidelines:
- Use ONLY the part number found in the first column of the parts list.
- The number stamped on a part is for the single part only, unless it includes set screws, studs, or other components that must be furnished in combination.
- Letters appearing after a part number indicate the style of finish (e.g., A for Hardened, Polished, Nickel Plated and Buffed; B for Polished, Nickel Plated and Buffed). These letters must be included when ordering.
- Parts marked with an asterisk (*) are furnished only when repairs are made at the factory.
Parts diagrams and lists
The document contains detailed exploded view diagrams (Plates) that correspond to the numerical parts lists. These diagrams help identify the location and assembly of components such as the bobbin winder, thread unwinder, hook, and presser bar mechanisms.
Important maintenance notes
- Use only genuine Singer needles marked with the SIMANCO trade mark.
- Needles in containers marked FOR SINGER MACHINES are not genuine Singer-made needles.
Manufacturer information
SINGER
Practical help
Common problems
Machine running stiffly or experiencing excessive wear
Apply Singer Type B or Type D oil to all oil holes marked 'OIL' at least twice daily.
Before use
- Ensure the machine is properly oiled with Type B or D oil.
- Verify the exact part number from the list before ordering.
- Check for finish codes (e.g., A, B, C) when ordering parts to ensure the correct finish.
- Use only genuine Singer needles marked with the SIMANCO trade mark.
Specs in practice
- Type B/D Oil
- Required lubricant for all movable contact parts.
- Finish Codes
- Letters after part numbers (e.g., A=Hardened/Polished, B=Polished/Nickel Plated) indicating the specific finish style.
Images and diagrams
- Diagrams (Plates) show exploded views of machine components.
- Numbers on diagrams correspond to the part numbers in the lists.
Model compatibility
- Needles marked 'FOR SINGER MACHINES' are not genuine Singer-made needles.
