User Manual for The Home Depot Bit Socket Set
Quick guide for The Home Depot Bit Socket Set. Includes safety instructions, detailed part lists for various models, maintenance tips, and torque specifications.
Quick answers from the manual
Quick answer
- This manual provides safety instructions, component lists for various bit socket sets, maintenance guidelines, and torque specifications for proper usage. p. 2, 3, 4, 7
Key actions
- Store the bit socket in the storage box after use to prevent loss. p. 7
- Clean tools promptly if dirt or dust is found. p. 7
Problems and fixes
Dirt or dust accumulation
Clean the tools in time.
p. 7Maintenance and reset
- Store indoors to avoid prolonged outdoor exposure. p. 7
Technical specifications
| Parameter | Value | Meaning | Pages |
|---|---|---|---|
| Torque | Varies by type (e.g., PH0: 1 N.M, T70: 599.2 N.M) | Maximum torque specifications for socket bits. | p. 7 |
Where to find it in the PDF
- Safety Instructions p. 3
- Part List p. 4, 5, 6
- Maintenance and Cautions p. 7
Table of contents
Quick guide from the manual
This manual provides essential safety, maintenance, and technical information for the Bit Socket Set. Users should read the manual carefully before use to reduce the risk of injury. The set is not a toy and must be kept away from children. Always store the tools in the provided storage box after use and keep them away from open flames and sharp objects.
Safety Instructions
- Usage: Use the bit socket only as intended. It is not a toy and should not be used by children.
- Handling: Do not use the bit socket to maliciously injure people.
- Fire Hazard: Keep away from open flames as the product box can ignite.
- Protection: Keep away from sharp points, blades, and other items that could scratch the product box.
Part List
The manual covers various set configurations, including models 32H, 18H, 13T, 34T, 10M, 60TE, 107 THE, and 31TE+adapter. Each set contains a specific assortment of socket bits (Metric and Imperial) and materials (S2 bit + CRV50BV30 socket).
Maintenance
- Storage: Always put the bit socket back into the storage box after use to avoid loss of parts. Store indoors to avoid prolonged outdoor exposure.
- Cleaning: If dirt and dust are found on the tools, clean them in time.
Torque Specifications
Do not exceed the specifications when using the socket bit, as this may cause damage. The manual provides a comprehensive reference table for torque values (in N.M) for various bit types (e.g., PH, T, H, SL, PZ series). For more details, refer to standards such as ISO 2936, ASEM B18, and DIN ISO 8764-1:2006.
Manufacturer information
The Home Depot
Practical help
Common problems
Dirt or dust accumulation on tools
Clean the tools promptly.
Loss of parts
Always return the bit socket to the storage box after use.
Before use
- Read the instruction manual carefully.
- Ensure the tool is used only for its intended purpose.
- Keep the product away from open flames.
- Keep the product away from sharp points and blades.
- Verify the correct torque specification for the specific bit type.
Images and diagrams
- The manual contains detailed tables listing the contents (socket sizes and types) for each specific model number (e.g., 32H, 18H, 13T, 34T, 10M, 60TE, 107 THE, 31TE).
Model compatibility
- The product is not a toy and must be kept away from children to prevent accidental ingestion.
