FLEX TS 92 18-EC Extremely Lightweight Cordless Table Saw

Product Description

The FLEX TS 92 18-EC is a high-performance, cordless table saw engineered for commercial use in industry and trade. It is designed for versatile cutting applications, including rip, cross, miter, bevel, and non-through cuts in a variety of wood and plastic materials.

Technical Data

• Voltage: 18 V
• No-load speed: 5000 /min
• Variable speed: 2000-5000 /min
• Blade size: 254 mm
• Max. bevel angle: 47°
• Max. cutting depth (90°): 92 mm
• Max. cutting depth (45°): 58 mm
• Weight (without battery): 23 kg

Safety Instructions

WARNING: Read all safety warnings, instructions, illustrations, and specifications provided with this power tool. Failure to follow all instructions may result in electric shock, fire, and/or serious injury.

• Always keep guards in place and in working order.
• Use the saw blade guard, riving knife, and anti-kickback device for every through-cutting operation.
• Never perform any operation "freehand". Always use the rip fence or miter gauge.
• Never reach over or in back of the rotating saw blade.
• Always stand to the side of the saw blade, never directly in line with it.

Setup and Operation

Before first use, remove the styrofoam block and cable tie. Ensure the table saw is placed on a level, well-lit surface. The saw features an auto-stop function that automatically shuts off the tool when a cut is complete. The speed can be adjusted using the variable-speed dial.

Maintenance

Regularly clean the power tool and the grille in front of the vent slots. Blow out the housing interior and motor with dry compressed air. Periodically lubricate all moving parts. Always remove the battery before performing any maintenance work.

Disposal

Do not dispose of electric power tools in household waste. In accordance with EU Directive 2012/19/EU, used power tools must be collected separately and recycled in an environmentally friendly manner.
