Guangdong 1276A Remote Control Off-Road Car User Guide
Quick start guide for the Guangdong 1276A RC car, covering battery installation, pairing, driving controls, and maintenance tips.
Table of contents
Quick guide from the manual
This document provides essential instructions for operating the Guangdong 1276A remote-controlled car. Key procedures include battery installation for both the vehicle and controller, pairing the devices, and basic driving operations. Please note that this product is not recommended for children under 6 years of age.
Battery installation
Before use, ensure both the car and the controller are switched to the OFF position.
- Car: Open the battery cover according to the arrow, insert the included 3.7V rechargeable battery, and secure the cover.
- Controller: Open the battery compartment and insert 2 x 1.5V AA batteries (included), ensuring correct polarity.
Operating the RC car
- Switch both the car and the controller to the ON position.
- Wait for the red light on the controller to stop flashing, which indicates successful pairing. Do not touch the steering wheel during this process.
- Use the controller steering wheel for left/right turns and the trigger/lever for forward/reverse movement.
- If the car does not drive straight, adjust the steering alignment lever located beneath the chassis.
- Press the High Speed Mode button on the controller to toggle high-speed performance.
Care and maintenance
- Always remove batteries from the toy if it will not be used for a long period.
- Wipe the toy gently with a clean, damp cloth.
- Keep the toy away from direct sunlight or heat sources.
- Do not submerge the toy in water to prevent damage to electronic components.
Battery safety information
- Do not short-circuit battery terminals.
- Rechargeable batteries must only be charged under adult supervision.
- Dispose of batteries properly; never throw them into fire as they may explode.
- The battery charger should be regularly inspected for damage to the cord, plug, or enclosure.
Practical help
Common problems
Car does not drive in a straight line
Adjust the steering alignment lever located beneath the chassis.
Controller light keeps flashing
Ensure the car is turned on and wait patiently for the pairing process to complete without touching the steering wheel.
Car loses performance or power
The rechargeable battery may need to be recharged or replaced.
Before use
- Ensure both car and controller are switched to OFF before inserting batteries.
- Check that the 3.7V rechargeable battery is correctly connected to the USB cable.
- Verify that 2 x 1.5V AA batteries are installed in the controller with correct polarity.
- Ensure the screwdriver is kept away from children after use.
- Confirm the charging time for the rechargeable battery is approximately 90 minutes.
Specs in practice
- Optimum charging time
- 90 minutes for the included 3.7V rechargeable battery.
- High Speed Mode
- A selectable mode via the controller button to increase vehicle speed.
- Steering alignment lever
- A manual adjustment tool under the chassis to correct vehicle tracking.
Images and diagrams
- The chassis diagram highlights the location of the steering alignment lever and the ON/OFF switch.
- The controller diagram identifies the High Speed Mode button, steering wheel, and power indicator.
- The battery compartment diagram shows the correct orientation for AA batteries in the controller.
Model compatibility
- Not recommended for children under 6 years of age.
- Use only the provided USB charging cable for the rechargeable battery.
