Haier Freezer User Manual

Quick guide from the manual

This freezer is designed for household use. Upon initial start-up, plug the appliance into a power socket. The temperature alarm may sound until the internal temperature drops below 0°C. You can silence the alarm manually by pressing the function button.

Safety information

• Electrical safety: Ensure the appliance is properly grounded. Do not damage the power cord. If the cord is damaged, it must be replaced by a qualified professional.
• Ventilation: Keep ventilation openings in the appliance enclosure or built-in structure clear of obstruction. Maintain at least 10cm of space around the freezer.
• Food storage: Do not store flammable materials, explosives, or corrosive chemicals in the freezer. Never store bottled beer or beverages as they may burst.
• Children: Ensure children do not play with the appliance.

Installation

Place the freezer on a flat, solid, and fire-resistant surface. If the freezer is unstable, adjust the feet by turning them clockwise or anticlockwise. Do not place the freezer in direct sunlight or near heat sources. After leveling and cleaning, let the appliance remain idle for at least 6 hours before switching it on.

Control panel and functions

The control panel allows you to manage temperature and special functions:

• Temperature setting: Press button A2 to adjust the temperature. The range is -14°C to -26°C.
• Fast Freezing: Select "S.FRZ" using button A3 and confirm with A4. This is ideal for freezing large quantities of fresh food.
• Eco Function: Select "ECO" using button A3 and confirm with A4. This optimizes energy consumption.
• Child Lock: Select the lock function using button A3 and confirm with A4 to prevent accidental setting changes.

Maintenance

The freezer features automatic defrosting; no manual operation is required. Clean the interior regularly with a soft cloth, warm water, and mild detergent. Always keep the door gasket clean. When moving the freezer, do not tilt it more than 45 degrees to avoid damaging the cooling system.

Troubleshooting

Before calling for service, check the following:

• Compressor does not work: Check if the plug is connected, the power is on, or if the freezer is in a defrost cycle.
• High temperature alarm: Ensure the door is closed properly and not opened too frequently. Check if too much food was added at once.
• Abnormal sounds: Ensure the freezer is on a level surface and not touching surrounding objects.
