User Manual for Hyundai VC 020B / VC 020O Stick Vacuum Cleaner
Quick guide for the Hyundai VC 020B and VC 020O 2-in-1 stick vacuum cleaner. Includes assembly, cleaning, maintenance, and safety instructions.
Table of contents
Manual images
Click an image to enlargeQuick guide from the manual
This vacuum cleaner is a 2-in-1 device that can be used as a stick vacuum or a handheld unit. Before use, ensure the local voltage matches the device specifications. Do not use the vacuum to clean liquids, hot ashes, or sharp objects like glass. Always ensure the filter and dust container are correctly installed before operation.
Product description
The vacuum consists of several key components: P1 Upper handle, P2 Handle folding button, P3 Handle foldable axis, P4 Power cord, P5 Plug, P6 Brush assembly, P7 Release button, P8 Main body, P9 Main switch, P10 Handheld vacuum, and P11 HEPA filter.
Assembly
To assemble the vacuum, carefully insert the floor brush into the vacuum compartment until it is securely attached. Ensure the device is placed within reach of a power socket but away from heat sources or wet areas.
Operation
To use as a stick vacuum, push the main switch away from you to start. Regularly check that the floor brush is clean to avoid scratching sensitive surfaces. To use as a handheld vacuum, press the release button (P7) to detach the handheld unit from the main body.
Cleaning and maintenance
Regular maintenance is essential for optimal performance. To clean the dust container, press the release button and turn the container to remove it. Empty the contents into a bin. The filter can be shaken clean or rinsed with warm water; ensure all parts are completely dry before reassembly. If the floor brush or wheel axles become jammed with hair or threads, turn off the device and carefully remove the debris using scissors or a screwdriver.
Technical specifications
- Type: 2-in-1 stick vacuum cleaner
- Power: 600 W
- Voltage: 230 V ~ 50 Hz
- Dust container capacity: 0.5 L
- Cable length: 7 m
- Filter: Permanent HEPA filter
Safety and disposal
Do not use the appliance if the power cord or plug is damaged. Keep the device away from children and do not allow them to play with it. This appliance is for private, indoor use only. At the end of its life, do not dispose of the device as household waste; follow local regulations for recycling electrical and electronic equipment.
Manufacturer information
Hyundai
Practical help
Common problems
Suction power is weak
Check if the dust container is full or if the filter is clogged. Clean or replace the filter.
Brush is jammed
Turn off the device and use scissors or a sharp knife to remove threads or hair entangled in the brush.
Wheel is jammed
Use a screwdriver to carefully remove the wheel, clean the axle of any debris, and press the wheel back into place.
Before use
- Check that the local power supply voltage matches the rating label.
- Ensure the device is fully assembled.
- Verify that the filter and dust container are correctly inserted.
- Ensure the floor brush is clean.
Specs in practice
- Dust container capacity
- 0.5 L
- Power cord length
- 7 m
- Power consumption
- 600 W
Images and diagrams
- P1-P11 labels identify the main parts of the vacuum, including the handle, release buttons, and filter.
Model compatibility
- Not intended for commercial use.
- Do not vacuum liquids, hot ashes, or sharp objects like glass splinters.
- Do not use in wet areas or outdoors.
