Installation Guide for LANCOM 1793VAW Router
Quick installation guide for the LANCOM 1793VAW router. Includes interface overview, initial setup steps, configuration methods (WEBconfig, LANconfig, LMC), and safety instructions.
Quick answers from the manual
Quick answer
- The LANCOM 1793VAW is a router. Initial setup involves connecting power and network cables, then configuring via WEBconfig (browser), LANconfig software, or LANCOM Management Cloud (LMC). p. 1
Key actions
- Connect power and network cables. p. 1
- Access WEBconfig via browser. p. 1
- Use LANconfig software for automatic discovery. p. 1
First start
- Connect cables, wait for boot, then use WEBconfig, LANconfig, or LMC to run the setup wizard. p. 1
Problems and fixes
Certificate warning
Select 'Advanced' to proceed.
p. 1
Device not found
Wait for boot completion.
p. 1Technical specifications
| Parameter | Value | Meaning | Pages |
|---|---|---|---|
| Power supply | 12 V DC | External power adapter | p. 1 |
| Dimensions | 210 x 45 x 140 mm | W x H x D | p. 1 |
Where to find it in the PDF
- Quick Installation Guide p. 1
Table of contents
Quick guide from the manual
This document provides the essential steps to install and configure your LANCOM 1793VAW router. It covers hardware connections, initial setup methods, and safety guidelines. Always ensure the device is placed in a well-ventilated area and connected to a stable power source before beginning configuration.
Interface overview
The front panel of the LANCOM 1793VAW features the following ports and interfaces:
- VDSL/ADSL interface: For DSL line connection.
- Ethernet interfaces (ETH 1-4): For network device connections.
- Analog interfaces: For analog telephony devices.
- ISDN interfaces: For ISDN devices.
- USB interface: For peripheral connection.
- Configuration interface (Config/COM): For serial configuration (not for network configuration).
- Power supply connector: For the 12V DC power adapter.
Initial start-up
Follow these steps to prepare your device for configuration:
- Connect power: Use the enclosed power supply unit.
- Connect network: If using a DSL modem, connect the DSL interface to the TAE socket. Connect other devices to the Ethernet ports as needed.
- Choose configuration method: Select one of the following options:
- WEBconfig: Connect via a web browser. If no DHCP server is active, use IP 172.23.56.254. If a DHCP server is active, access the device via https://LANCOM-DDEEFF (replace DDEEFF with the last six digits of the MAC address).
- LANconfig: Use the Windows software available at www.lancom-systems.com/downloads. The software will automatically discover the unconfigured device in the local network.
- LANCOM Management Cloud (LMC): Follow instructions at www.lancom-systems.com/lmc-access.
Safety instructions
To ensure safe operation, observe the following:
- Do not open the device housing; unauthorized repairs void the warranty.
- Mount or demount antennas only while the device is powered off.
- Ensure adequate air circulation and do not obstruct ventilation slots.
- The device must be freely accessible and not installed under plaster.
- In case of emergency (damage, ingress of liquids), disconnect the power supply immediately.
Technical data
- Power supply: 12 V DC, external power adapter.
- Dimensions: 210 x 45 x 140 mm (W x H x D).
- Housing: Robust synthetic housing, ready for wall mounting, includes Kensington lock.
Official resources from the manual
Manufacturer information
LANCOM Systems GmbH
Practical help
Common problems
Certificate warning in browser
If a certificate warning appears when connecting via WEBconfig, click 'Advanced' or the equivalent option in your browser to proceed to the device page.
Device not found in LANconfig
Wait for the device to finish the booting process before starting the LANconfig software.
Cannot configure via network
Ensure you are not using the CONFIG or COM interface for network configuration; these are for serial connections only.
Before use
- Connect the power supply unit.
- Connect the DSL cable to the VDSL/ADSL interface if required.
- Connect Ethernet cables to the ETH ports.
- Ensure the device is placed in a well-ventilated area.
- Verify the device is not covered or stacked.
Specs in practice
- Power supply
- 12 V DC, external power adapter.
Images and diagrams
- The front panel diagram identifies the VDSL/ADSL, Ethernet, Analog, ISDN, USB, and Power ports.
- The CONFIG/COM port is clearly marked and is not intended for standard network configuration.
Model compatibility
- The CONFIG or COM interface is not suitable for network configuration.
- Only use the enclosed power supply or the one listed in the hardware quick reference.
