Philips LED HID Replacement Lamps Resource Guide
A comprehensive resource guide for Philips LED HID replacement lamps, featuring product matrices, application compatibility, and technical specifications for retrofitting high-intensity discharge lighting.
Quick answers from the manual
Quick answer
- This document is a resource guide for selecting Philips LED replacement lamps for HID fixtures. It includes a product matrix for matching replacements to existing HID wattage and application types, as well as technical features for the CorePro Glass LED HID line. p. 1, 2
Key actions
- Match your existing HID wattage and application type using the product matrix to select the appropriate LED replacement. p. 2
Technical specifications
| Parameter | Value | Meaning | Pages |
|---|---|---|---|
| Operational Temperature | -20-45°C | Safe operating temperature range. | p. 2 |
| Surge Protection | 2KV | Protection against voltage spikes. | p. 2 |
| CRI | 80 | Color Rendering Index. | p. 2 |
Show 1 more answers Show less
Where to find it in the PDF
- Product Matrix and Features p. 2
- Resources and Contact p. 3
Table of contents
Manual images
Click an image to enlargeQuick Guide to Philips LED HID Replacements
This document serves as a marketing and technical resource guide for selecting Philips LED replacement lamps for existing High-Intensity Discharge (HID) fixtures. It provides a matrix for matching LED replacements to existing HID wattage and application types, along with key technical features of the CorePro Glass LED HID line.
CorePro Glass LED HID Lamps
The CorePro Glass LED HID lamps are designed to provide an easy and short payback solution for replacing conventional HID lamps. They feature a unique high-power LED filament technology in a full glass bulb, offering a familiar look and feel.
Key Benefits
- Compact design suitable for existing HID fixtures.
- Frosted glass housing for a traditional appearance.
- Patented high-power LED filament design for superior light quality and uniformity.
- Suitable for both indoor and outdoor applications.
- Compatible with both enclosed and open fixtures.
- Low initial investment with short payback time.
Applications and Compatibility
The guide provides a product matrix to assist in selecting the correct LED replacement based on the original HID lamp wattage and the specific application environment. Common applications include:
- High ceiling indoor areas, warehouses, gymnasiums, and schools.
- Street lighting, pedestrian walkways, and outdoor parking lots.
- Public spaces, parks, squares, and plazas.
- Industrial buildings and warehouses.
- Outdoor walls of commercial structures.
Technical Features
The CorePro Glass LED HID lamps are built with the following specifications:
- Operational Temperature: -20°C to 45°C.
- Surge Protection: 2KV.
- Color Rendering Index (CRI): 80, suitable for both indoor and outdoor use.
Contact Information
For further assistance, contact Signify North America Corporation at 855-486-2216 or Signify Canada Ltd. at 800-668-9008.
Manufacturer information
Philips
Practical help
Common problems
Selecting the wrong replacement lamp
Use the product matrix in the guide to match the existing HID wattage (e.g., 70W, 100W, 150W, 175W, 250W) with the corresponding LED replacement model.
Compatibility with fixture type
Verify if the fixture is enclosed or open; the CorePro Glass LED HID lamps are suitable for both.
Before use
- Identify the wattage of the existing HID lamp being replaced.
- Determine the application type (e.g., High bay, Post top, Wall pack).
- Confirm the fixture environment (indoor vs. outdoor).
- Check if the fixture is enclosed or open.
Show more Show less
Specs in practice
- 2KV Surge Protection
- Built-in protection against electrical surges up to 2000 volts.
Images and diagrams
- The product matrix on page 2 maps HID wattage (70W to 250W) to specific LED replacement types (Corn Cob Gen 2, Wall Packs, High Bay Gen 2) based on the application.
Model compatibility
- Suitable for both enclosed and open fixtures.
- Designed for indoor and outdoor applications.
