Shada 1110IM 6W LED Luminaire User Guide
Installation and safety instructions for the Shada 1110IM 6W LED Luminaire, including mounting steps and maintenance guidelines.
Table of contents
Product Overview
The Shada 1110IM is a 6W LED luminaire designed for indoor use. This fixture provides efficient lighting and is intended for fixed installation. It operates on a standard 220-240V 50/60Hz power supply.
Safety Information
Before installation, ensure the power supply is disconnected. Installation should be performed by a qualified electrician to avoid the risk of electric shock. The luminaire is not intended for use in environments where it may be exposed to water or extreme conditions. Do not modify the product, as this may damage the device or cause injury. If the luminaire or its components are damaged, do not use the product.
Installation
The installation process involves mounting the fixture to a solid surface. Ensure the mounting area can support the weight of the luminaire. Use the provided mounting hardware to secure the base. Connect the power wires according to the local electrical regulations, ensuring a secure connection to the terminal block. Once the base is secured and wired, snap the luminaire housing into place.
Maintenance and Cleaning
To maintain the luminaire, clean it periodically with a soft, dry cloth. Do not use abrasive cleaners or chemicals, as these may damage the surface finish. The light source in this luminaire is non-replaceable; if the light source reaches the end of its life, the entire luminaire must be replaced.
Disposal
This product is subject to the WEEE directive. Do not dispose of the luminaire with household waste. It must be taken to a designated collection point for electronic waste to ensure environmentally friendly recycling.
Manufacturer information
Shada B.V.
Practical help
Common problems
Luminaire does not turn on
Check if the power supply is connected correctly and ensure the circuit breaker is active.
Damaged housing or cable
Do not attempt to repair; the unit must be replaced if the housing or power cable is compromised.
Before use
- Ensure the power supply is switched off at the main breaker.
- Verify that the mounting surface is stable and suitable for the fixture.
- Check that all necessary mounting hardware is included.
- Confirm the voltage matches the 220-240V requirement.
Images and diagrams
- Steps 1-3: Power disconnection and preparation.
- Steps 4-6: Drilling and mounting the base bracket.
- Steps 7-8: Wiring the terminal block.
- Steps 9-12: Attaching the luminaire to the bracket and final power-on.
Model compatibility
- The light source is non-replaceable.
- Designed for indoor use only.
- Not compatible with external dimmers.
