Sony E 18-135mm F3.5-5.6 OSS (SEL18135) Lens

Product Overview

The Sony E 18-135mm F3.5-5.6 OSS (SEL18135) is a high-performance interchangeable lens designed specifically for Sony E-mount cameras. It features built-in optical image stabilization (OSS) to help reduce blur during handheld shooting.

Safety Precautions

To prevent fire, electric shock, or damage to the equipment, observe the following:

• Do not leave the lens exposed to direct sunlight or bright light sources, as this can cause internal damage or fire.
• When shooting against the sun, keep the sun completely out of the angle of view.
• Always attach lens caps when the lens is not in use.
• When carrying the camera with the lens attached, hold both the camera and the lens firmly.

Installation and Operation

To attach the lens, align the white mounting index on the lens barrel with the white index on the camera body. Insert the lens and rotate it clockwise until it locks. To remove, hold down the lens release button on the camera and rotate the lens counterclockwise.

The lens features a zoom ring for adjusting focal length and a focus mode switch to toggle between Auto Focus (AF) and Manual Focus (MF). For AF operation, ensure both the camera and lens are set to AF mode.

Lens Hood and Flash Usage

Using the included lens hood helps reduce flare and ensures optimal image quality. Align the red line on the hood with the red line on the lens and rotate clockwise until it clicks. When using a built-in or external flash, remove the lens hood to prevent shadows from appearing in your images.

Maintenance and Troubleshooting

If the corners of the screen appear darker than the center (vignetting), close the aperture by 1 to 2 stops. Keep lens contacts clean and avoid touching them. If the lens requires service, contact your local authorized Sony dealer or service facility.

Technical Specifications

• Focal length: 18-135mm
• 35mm equivalent focal length: 27-202.5mm
• Lens groups-elements: 12-16
• Minimum focus distance: 0.45m (1.48 ft)
• Maximum magnification: 0.29x
• Minimum aperture: f/22-f/36
• Filter diameter: 55mm
• Weight: Approx. 325g (11.5 oz)
