User Manual for Sygonix Outdoor Wi-Fi Camera 1080p

Quick Guide

The Sygonix Outdoor Wi-Fi Camera 1080p is designed for outdoor surveillance, connecting via a 2.4 GHz WLAN network and the Smart Life - Smart Living app. It features motion detection, night vision, and IP65 weather protection. Ensure you have a 2.4 GHz Wi-Fi network available and the Smart Life app installed on your mobile device before beginning.

Product Overview

The camera features the following components:

• Compartment cover: Protects the internal slot and reset button.
• Speaker: For 2-way audio communication.
• Inside compartment: Contains the MicroSD card slot and Reset button.
• Microphone: For audio recording.
• IR-LEDs: 8 LEDs for night vision (behind tinted cover).
• Lens: Camera lens.
• Light sensor: Automatically triggers night vision.
• USB power cable: For power supply.
• Bracket mounting points: For wall installation.

Installation

Before installation, remove the protective film from the camera lens.

Choosing a Location

• Ensure the camera is within range of your Wi-Fi access point.
• Consider the recording angle and sensor detection range.
• The power cable is 2.3 m long; ensure a suitable power outlet is nearby.
• If used outdoors, ensure the cable and adapter are protected against water and dust.

Mounting

1. Use the holes on the mounting plate as a template to mark drilling spots.
2. Insert plastic dowels if necessary.
3. Fix the mount to the wall using the supplied screws.
4. Screw the camera onto the mount.
5. Ensure the camera is securely attached before letting go.

Getting Started

MicroSD Card

The camera supports MicroSD cards (Class 10, max 128 GB). The card must be formatted to FAT32. Insert the card into the slot inside the compartment until it clicks. To remove, press the card until it clicks and ejects.

Pairing

1. Connect the camera to power.
2. If not paired, the camera will emit two beeps and repeat them every 15 seconds.
3. In the Smart Life app, select Add device, then Video Surveillance, then Smart Camera.
4. Follow the app instructions to complete the connection.

Operation

Night Vision

The camera is equipped with a light sensor that automatically activates night vision when ambient light is low. Images will be recorded in black and white. Avoid placing the camera behind glass, as infrared glare may overexpose the image.

Motion Detection

• With MicroSD card: 15-second clips are saved when motion is detected until the card is full. You will receive push notifications.
• Without MicroSD card: No clips are saved. You will receive push notifications and can view live video via the app.

Resetting the Camera

If the camera malfunctions or needs to be re-paired:

1. Open the compartment cover.
2. Press and hold the Reset button for 4-5 seconds until a long beep is heard.
3. Wait for the system to restart and enter pairing mode.
4. If previously paired, remove the device from the app before re-pairing.

Maintenance and Cleaning

• Disconnect from power before cleaning.
• Use a fibre-free, slightly dampened cloth.
• Do not use aggressive cleaning agents, alcohol, or chemical solvents.
• Do not apply excessive force to the solar panels (if applicable) or the camera housing.

Technical Data

• Resolution: 1920 x 1080p (HD)
• Field of View: 90° horizontal, 80° vertical
• Ingress Protection: IP65
• Power Input: 5 V/DC, 1 A
• Wireless: IEEE 802.11 b/g/n, 2.4 GHz
• Operating Temperature: -20 to +40 °C
