User Manual for Homcom F00-001V70 Fog Machine

Quick guide from the manual

This fog machine is designed for indoor use to create atmospheric effects. Before operation, ensure the tank is filled with appropriate fog fluid and the machine is placed on a stable, level surface. The device requires a 2-3 minute preheating period before it is ready to emit fog.

Safety warnings

• Danger of burns: The fog nozzle becomes extremely hot (up to 600°F). Keep flammable items at least 3 feet away from the nozzle.
• Danger of explosion: Never add flammable liquids (gas, oil, alcohol, perfumes) to the water tank. Use only dedicated fog fluid.
• Electric shock: Disconnect the appliance from the power supply before refilling fluid, cleaning, or performing maintenance. Do not use outdoors.
• General safety: Keep out of reach of children. Never leave the machine unattended while in operation. Ensure at least one foot of space around the machine for ventilation.

How to use

1. Pour fog fluid into the water tank. Ensure the metal liquid nozzle is fully immersed in the fluid; otherwise, the equipment will not work properly.
2. Plug the power cord into a power socket and turn on the machine.
3. Wait 2-3 minutes for preheating. A red light on the wireless receiver indicates it is heated and ready to spray.
4. Press the red button on the wireless receiver or the unlock button on the remote control to start spraying.
5. Press the lock button on the remote to stop spraying.
6. The machine has a 5-minute auto-protection shutdown if it overheats. It will restart automatically after cooling down.

Remote control

The remote control allows you to toggle the fog output and adjust the LED light colors. The remote uses a CR2025 battery (not included).

Maintenance

• After about a month of use, clean the machine by adding a mixture of 20% distilled water and 80% vinegar to the water tank and running the machine for 10-30 minutes.
• After cooling down, reinstall the nozzle and add fresh fog fluid.
• Clean the exterior with a dry cloth and store in a dry place.

Technical specifications

• Voltage: 220-240V~50/60Hz
• Warm-up time: 2-3 minutes
• Oiler capacity: 0.3 liters

Battery safety

This product contains a button cell battery. Keep new and used batteries out of reach of children. If swallowed, seek immediate medical attention. Do not dispose of batteries in household trash.
