Sicce JOLLY 10W Submersible Heater User Manual

Quick guide from the manual

The Sicce JOLLY is an automatic, fully submersible plastic heater designed for indoor fresh and marine water aquariums, paludariums, and turtle tanks. Important: Never operate the heater outside of water. Always disconnect all aquarium appliances before performing installation or maintenance.

Installation

1. Check the heater label to ensure the voltage matches your power supply.
2. Attach the suction cups to the heater.
3. Place the heater inside the aquarium in a position with good water circulation, preferably near a source of water movement to ensure even heat distribution.
4. Do not plug the heater into the power supply until it is fully submerged in water.
5. Ensure the heater remains submerged at all times.

Operation

The heater increases water temperature according to the capacity of the aquarium, room temperature, and desired increase (refer to Table 1 in the manual). The LED on the tube indicates the heater status:

• LED ON: Heater is in operation.
• LED OFF: Thermal protection is activated.

When the heater is removed from the water or reaches its maximum temperature, the thermal protection automatically switches it off after a few minutes. For safety, unplug the heater and let it cool for at least 15 minutes before removing it from the water.

Maintenance

The heater requires no maintenance other than periodic cleaning of the tube to remove salt incrustations and algae. Use only water and vinegar for cleaning. Do not use chemical cleaners, solvents, or acids. Do not disassemble the heater or pull on the power supply cable.

Safety

• If the appliance shows signs of abnormal water leakage, immediately unplug it.
• Maximum operating depth is 1 meter (3 feet).
• Use a drip-loop (fig. 1) for each cord connecting an aquarium appliance to an outlet to prevent water from traveling along the cord and contacting the outlet.
• If the plug or socket gets wet, do not unplug the cord. Disconnect the fuse or circuit breaker supplying power to the appliance first.
• This appliance is not intended for use by persons with reduced physical, sensory, or mental capabilities unless supervised.
• The power cord cannot be replaced; if damaged, the appliance must be discarded. Never cut the cord.
