User manual for Thomann 12-280/8-A loudspeaker
Quick start guide for the Thomann 12-280/8-A loudspeaker. Includes safety instructions, technical specifications, and handling guidelines for proper installation.
Table of contents
Quick guide from the manual
This document provides essential safety and operational information for the Thomann 12-280/8-A loudspeaker. It is intended for users installing the driver into a suitable housing. Always retain this guide for future reference.
Safety instructions
To ensure safe operation and prevent damage to the product or hearing, observe the following:
- Intended use: The device must be installed in a suitable housing to convert electrical signals into acoustic signals. Any other use is considered improper.
- Polarity: Always observe correct polarity when connecting the loudspeaker to an amplifier output. Reverse polarity can cause damage to the speaker.
- Environment: Do not use the product in extreme temperatures, high humidity, extremely dusty or dirty areas, or locations where it can become wet.
- Handling: Do not use force when handling the product. Never immerse in water; clean only with a dry cloth.
- Hearing safety: Do not operate the device continuously at high volume to avoid temporary or permanent hearing impairment.
Technical specifications
The Thomann 12-280/8-A features the following specifications:
- Diameter: 300 mm
- Impedance: 8 Ohm
- Power handling: 280 W RMS (1120 W Peak)
- Sensitivity (1 W / 1 m): 95 dB ± 2 dB
- Frequency response: 50 Hz - 4.0 kHz
- Min. resonance frequency: 50 Hz ± 5 Hz
- Voice coil diameter: 75.5 mm
- Voice coil material: Round copper wire
- Voice coil formers material: TIL
- Voice coil height: 19 mm
- Magnet depth: 8 mm
- Flux density: 0.95 T
Disposal
This product is subject to the European Waste Electrical and Electronic Equipment Directive (WEEE). Do not dispose of the device with normal household waste. Dispose of it through an approved waste disposal firm or your local waste facility in compliance with local regulations.
Practical help
Common problems
Speaker damage
Ensure correct polarity is observed when connecting the loudspeaker to the amplifier output. Reverse polarity can damage the unit.
Hearing impairment
Do not operate the device continuously at high volume. Turn down the volume immediately if background noise or hearing failure occurs.
Before use
- Ensure the speaker is installed in a suitable housing before operation.
- Verify that the amplifier output is compatible with the 8 Ohm impedance of the speaker.
- Check that the installation environment is free from extreme temperatures, humidity, and excessive dust.
- Confirm that all packaging materials have been removed and disposed of properly.
Specs in practice
- Impedance (8 Ohm)
- The electrical resistance of the speaker; ensure your amplifier is rated to drive 8 Ohm loads.
- Power handling (280 W RMS)
- The continuous power the speaker can handle without damage.
- Sensitivity (95 dB)
- Indicates how loud the speaker is at a distance of 1 meter with 1 Watt of power.
Images and diagrams
- The dimensions diagram provides the physical measurements required for mounting the speaker into a housing.
- The frequency response graph illustrates the output levels across the frequency spectrum (50 Hz to 4 kHz).
Model compatibility
- Requires a suitable external housing for proper operation.
- Designed for use with amplifiers capable of driving 8 Ohm loads.
