User Manual for Tripp Lite 10,000mAh Dual-Port Mobile Power Bank UPB-10K0-2U

Quick guide from the manual

The Tripp Lite 10,000mAh Mobile Power Bank features a side-mounted button to control operations and check status. Press the button once to check remaining battery capacity via the LED indicators. Hold the button down to turn off the LED indicators and stop charging. Press the button twice to toggle the built-in LED flashlight on or off.

Charging your mobile devices

To charge your smartphone, tablet, or other USB device:

1. Connect your device to the USB-A port on the power bank using the included USB Micro-B cable or a cable suitable for your device.
2. Charging will begin automatically.
3. The LED indicators will illuminate to show the remaining battery capacity of the power bank.

Charging the power bank

To recharge the power bank:

1. Connect the Micro-B port on the power bank to a USB-A port on a computer or a USB wall charger using the included USB Micro-B cable.
2. The LED indicators will flash or illuminate to show the charging progress.

LED indicator guide

The LED indicators provide status updates based on the current operation:

• 75-100% Capacity: 4 LEDs solid
• 50-75% Capacity: 3 LEDs solid
• 25-50% Capacity: 2 LEDs solid
• 5-25% Capacity: 1 LED solid
• 0-5% Capacity: 0 LEDs

When charging the power bank itself, the LED patterns indicate progress, with flashing lights representing the current charging stage.

Safety instructions

• Ensure the power bank is fully charged before first use.
• Charge the battery at least every three months to maintain battery health.
• Do not expose the device to temperatures above 140°F (60°C) when not in use or 113°F (45°C) when in use.
• Keep the device dry; do not immerse in water or use corrosive cleaners.
• Do not attempt to disassemble, modify, or puncture the unit.
• If the device enters protection mode (LEDs turn off and it will not charge), use an external charger to replenish the charge and reset the unit.

Specifications

• Input: 5V, 2A
• Output: USB 1: 5V, 1A / USB 2: 5V, 2A
• Operating Temperature: 32° to 113°F (0° to 45°C)
• Dimensions: 4.7 x 3.1 x 0.9 in. (120 x 78 x 23 mm)
• Weight: 0.6 lb. (0.27 kg)
