UGREEN 10-in-1 USB-C Hub (CM639) User Guide

Quick Guide

The UGREEN 10-in-1 USB-C Hub (CM639) is a versatile docking station designed to expand the connectivity of your USB-C enabled laptop, tablet, or smartphone. This device supports high-speed data transfer, high-resolution video output, and power delivery.

Device Overview

The hub features a comprehensive array of ports to support various peripherals:

• Video Output: 1x HDMI and 1x DisplayPort, both supporting up to 4K resolution at 60Hz.
• Power Delivery: 1x USB-C PD port supporting up to 100W power input for charging your host device.
• Data Ports: 2x USB-A 3.2 Gen 2 ports and 1x USB-C 3.2 Gen 2 port, all capable of 10Gbps data transfer speeds.
• Networking: 1x RJ45 Ethernet port supporting up to 1000Mbps (Gigabit) speeds.
• Storage: SD and TF card slots for memory card access.
• Audio: 3.5mm audio jack for headphones or microphones.

Usage and Compatibility

To ensure optimal performance, please note the following:

• Plug and Play: The device is generally plug-and-play on most modern operating systems (Windows, macOS, Linux).
• Video Output Requirements: For HDMI and DisplayPort functionality, ensure your host device's USB-C port supports DisplayPort Alt Mode (DP Alt Mode).
• Power Delivery: To achieve 100W charging, ensure your power adapter and cable are rated for 100W output. The hub will reserve a small amount of power for its own operation.
• Data Transfer: USB 3.2 Gen 2 ports provide high-speed data transfer. Ensure your connected devices and cables are also rated for 10Gbps to achieve maximum speeds.
